Build
| Frame |
Series 4 Alloy Frame, 150mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor BB Standard:Â BSA, 73mm, Threaded Color:Â Gloss Grey / Black |
|---|---|
| Fork |
Fox 38 Performance Elite, 160mm travel, 29″, 110x15mm Boost Kabolt Thru-Axle, 44mm Offset, Integrated Fox Fender Travel:Â 160mm Spring Type:Â Air |
| Shock |
Fox DHX2, Performance Elite, Low Speed Compression and Rebound Adjustment, 205x65mm, Trunnion Upper Mount, 25mmxM8 Lower Mount, S/M Spring Rate = 350lb, L/XL Spring Rate = 450lb Travel:Â 150mm Spring Type:Â Coil |
| Bottom Bracket |
BSA, 73mm, threaded |
| Headset |
FSA No 57, Sealed Cartridge Bearings, 1 1/8″ x 1 1/2 |
| Stem |
Marin CNC, 35mm Length, 35mm Bar Bore |
| Handlebar |
Marin Trail, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back |
| Saddle |
Marin eMTB Saddle |
| Seatpost |
X-Fusion Manic, 1x Composite Remote, Size S 125mm Travel, Size M and L 150mm Travel, Size XL 170mm Travel, 30.9mm Type:Â Dropper |
| Pedals |
Marin MTB Plastic |
| Grips |
Marin Grizzly Lock On |
Groupset
| Rear Derailleur |
Shimano XT 12-Speed, SGS |
|---|---|
| Crank |
Shimano XT M8150, 160mm Length, 38t Chainring |
| Shifters |
Shimano SLX 12-Speed, I-Spec EV |
| Cassette |
SunRace, 12-Speed, Microspline, 10-51T |
| Chain |
KMC E12S, eMTB-Specific Chain |
| Brakes |
Shimano SLX 4-piston Hydraulic Disc, 203mm rotor Type:Â Hydraulic Disc |
| Brake Levers |
Shimano SLX, I-Spec EV |
Wheels
| Rims |
Front: Marin Aluminum Double Wall, 29″ Diameter, 32mm Inner Rim Width, Sleeved Joint, Disc Specific, Tubeless Compatible; Rear: Marin Aluminum Double Wall, 27.5″ Diameter, 38mm Inner Rim Width, Sleeved Joint, Disc Specific, Tubeless Compatible |
|---|---|
| Spokes |
14g Black Stainless Steel |
| Front Hub |
Shimano FH-TC500, 110x15mm, Centerlock, 32H |
| Rear Hub |
Shimano FH-TC500MSB, 148x12mm, Disc, MicroSpline Freehub Body |
| Tires |
Front: Vee Tire Co. Attack HPL, 29×2.5″, Top 40 Tubeless Compatible, Rear: Vee Tire Co. Crown Gem, 27.5×2.8, TACKEE Compound, Tubeless Compatible |
Electric Components
| Motor |
Shimano Steps EP801 Drive Unit, 250W, 85Nm, 20MPH Top Assisted Speed |
|---|---|
| Battery |
BT-EN806 Internal 630Wh Recycling Program:Â Â Call2Recycle |
| Display |
Shimano SC-E600 |
