Build
| Frame |
All New Series 4 Alloy Frame, 140mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor Color:Â Gloss Tan / Black |
|---|---|
| Fork |
RockShock Pike Base 29″, Motion Control Damper, 140mm Travel, Maxle Stealth Axle, 42mm Offset Travel:Â 140mm Spring Type:Â Air |
| Shock |
RockShox Deluxe Select+, Compreson and Rebound Adjustment, 210×50, 25xM8 Lower and Upper Mount Travel:Â 140mm |
| Headset |
FSA No 57E, Sealed Cartridge Bearings, 1 1/8″ x 1 1/2 |
| Stem |
Marin 3D Forged Alloy, 35mm |
| Handlebar |
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5 Up, 9 Back |
| Saddle |
Marin eMTB Saddle |
| Seatpost |
TranzX, YSP23JL, 1x Remote, Size S 150mm Travel, Size M and L 170mm Travel, Size XL 200mm Travel, 30.9mm Type:Â Dropper |
| Pedals |
Marin MTB Plastic |
| Grips |
Marin Grizzly Lock On |
Groupset
| Rear Derailleur |
Shimano Deore, Direct Attachment, 11-Speed, SGS |
|---|---|
| Crank |
Shimano EM600, 160mm Length, 38t Chainring |
| Shifters |
Shimano Deore, 11-Speed, I-Spec EV |
| Cassette |
SunRace 11-Speed, 11-51T |
| Chain |
KMC X-10E, Silver |
| Brakes |
Tektro Slate EVO, 4-Piston Hydraulic Disc, Resin Pads, 203mm Rotor, w/ Bolt on Speed Sensor Type:Â Hydraulic Disc |
| Brake Levers |
Tektro Slate EVO Hydraulic Lever, I-Spec EV Compatible |
Wheels
| Rims |
Marin Aluminum Double Wall, 29″ Diameter, 29mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible |
|---|---|
| Spokes |
14g Black Stainless Steel |
| Front Hub |
Shimano FH-TC500, 110x15mm, Centerlock, 32H |
| Rear Hub |
Shimano HB-TC500, 148x12mm, Centerlock, Standard Freehub Body |
| Tires |
Vee Tire Co Attack HPL, 29×2.5″, Top 40 Tubeless Compatible, Override E-Specific Casing |
Electric Components
| Motor |
Shimano Steps EP6 Drive Unit, 250W, 85Nm |
|---|---|
| Battery |
Shimano BT-EN806, Internal 630Wh Recycling Program:Â Â Call2Recycle |
| Display |
Shimano SC-E600 |
