Build
| Frame |
All New Series 4 Alloy Frame, 140mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor BB Standard:Â BSA, 73mm, Threaded Color:Â Gloss Tan / Black |
|---|---|
| Fork |
Fox 36 Performance Elite, 140mm travel, 29″, 110x15mm Boost Kabolt Thru-Axle, 44mm Offset, Integrated Fox Fender Travel:Â 140mm Spring Type:Â Air |
| Shock |
Fox Float X, Performance Elite Series, EVOL Air Spring, Climb Switch, Rebound Adjustment, Custom Tune, 210x55mm, M8x30mm Top, M8x25mm Bottom Travel:Â 140mm |
| Bottom Bracket |
BSA, 73mm, threaded |
| Headset |
FSA No 57, Sealed Cartridge Bearings, 1 1/8″ x 1 1/2 |
| Stem |
Marin CNC, 35mm Length, 35mm Bar Bore |
| Handlebar |
Marin Trail, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back |
| Saddle |
Marin eMTB Saddle |
| Seatpost |
X-Fusion Manic, 1x Composite Remote, Size S 125mm Travel, Size M and L 150mm Travel, Size XL 170mm Travel, 30.9mm Type:Â Dropper |
| Pedals |
Marin MTB Plastic |
| Grips |
Marin Grizzly Lock On |
Groupset
| Rear Derailleur |
Shimano, Deore XT RD-M8130, 11-Speed, SGS, LinkGlide |
|---|---|
| Crank |
Shimano XT M8150, 160mm Length, 38t Chainring, 20MPH Top Assisted Speed |
| Shifters |
Shimano Deore XT SL-M8130-R, LinkGlide, I-Spec EV |
| Cassette |
Shimano XT LinkGlide LG-600, 11-Speed, 10-50T |
| Chain |
KMC E-11S |
| Brakes |
TRP DH-R EVO 4-Piston Hydraulic, 203mm Rotor, 2.3mm Thick Type:Â Hydraulic Disc |
| Brake Levers |
TRP DH-R EVO |
Wheels
| Rims |
Marin Aluminum Double Wall, 29″ Diameter, 29mm Inner Rim Width, Sleeved Joint, Disc Specific, Tubeless Compatible |
|---|---|
| Spokes |
14g Black Stainless Steel |
| Front Hub |
Shimano FH-TC500, 110x15mm, Centerlock, 32H |
| Rear Hub |
Shimano HB-TC500, 148x12mm, Centerlock, Standard Freehub Body |
| Tires |
Vee Tire Co Attack HPL, 29×2.5″, Top 40 Tubeless Compatible, Override E-Specific Casing |
Electric Components
| Motor |
Shimano Steps EP801 Drive Unit, 250W, 85Nm, 25 km/h Top Assisted Speed |
|---|---|
| Battery |
Shimano BT-EN806, Internal 630Wh Recycling Program:Â Â Call2Recycle |
| Display |
Shimano SC-E600 |
