Build
| Frame |
Robust and rigid frame construction thanks to Octatube (8 angular down tube) – made of special 6061-T6 aluminum MAXX Custom tubing. |
|---|---|
| Fork |
Mastodon Pro Extension, airspring, 150 mm, TA 15 x 150 mm Travel:Â 150mm Spring Type:Â Air |
| Shock |
Manitou Mara Pro 205 X 62,5, frame S Fox Float DPS TR 185×55 Travel:Â 146mm |
| Headset |
Acros Block-Lock, tapered, w/ 150 steering angle limitation |
| Stem |
e*thirteen Base |
| Handlebar |
e*thirteen Base 800 x 20, 35 mm |
| Saddle |
Selle Italia Man Flow |
| Seatpost |
MAXX Premium w/QR Type:Â Rigid |
| Pedals |
Flat Pedal CNC, sealing bearings |
Groupset
| Rear Derailleur |
Shimano XT RD M8130 |
|---|---|
| Crank |
MAXX SX 34T |
| Shifters |
Shimano XT SL M8130 |
| Cassette |
Shimano CS LG700 11-50 Z, 1 x 11 |
| Chain |
Shimano 11-fach CNHG601 |
| Brakes |
Shimano BR-M6120 4 piston- Disc 203/180 mm Type:Â Hydraulic Disc |
Wheels
| Rims |
Gipiemme Magnus 80, 32 H, FV, black |
|---|---|
| Front Hub |
SunRingle SRC Disc 6H, through axle 15/150 mm |
| Rear Hub |
SunRingle SRC Disc 6 H, Through Axle 12/197 mm |
| Tires |
Schwalbe Al Mighty 4.8″ 120-559 TLE |
Electric Components
| Motor |
Shimano EP801, 85 Nm, max. support 400% |
|---|---|
| Battery |
726 Wh, incl. 4A charger |
