Build
| Frame |
eBIG.NINE LITE, material: aluminium *max. wheelsize 29×2.20″ without fender max./ 29″x2.00″ with fender max. wheelsize, 148x12mm axle standard, MUK 37 Hanger BB Standard:Â BSA, Threaded |
|---|---|
| Fork |
SR Suntour XCM32 DS, Coil, 100mm, Tapered, 47mm fork offset, 29×2.4″ max wheelsize Travel:Â 100mm Spring Type:Â Coil |
| Bottom Bracket |
BSA, threaded |
| Headset |
MERIDA 2341 |
| Stem |
MERIDA EXPERT CC, material: aluminium, 31.8mm diameter, 5 stem angle, 80 mm-M, 90 mm-L, 100 mm-XL |
| Handlebar |
MERIDA EXPERT CC, material: aluminium, 720mm width, 10mm rise |
| Saddle |
MERIDA COMP SL, V-mount |
| Seatpost |
MERIDA EXPERT, material: aluminium, 30.9mm diameter, 15mm setback Type:Â Rigid |
| Pedals |
VP VPE-537 |
Groupset
| Rear Derailleur |
Shimano Alivio M3100, SGS |
|---|---|
| Crank |
Shimano CRE70-B, 34 teeth |
| Shifters |
Shimano Alivio |
| Cassette |
Shimano HG200, 11-36 teeth, 9 speed |
| Chain |
KMC e9S |
| Brakes |
Shimano MT200, 2 piston Type:Â Hydraulic Disc |
Wheels
| Rims |
MERIDA COMP CC, 20mm inner width, material: aluminium |
|---|---|
| Front Hub |
Shimano MT400 / Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Rear Hub |
Shimano MT400 / Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Tires |
Front: Maxxis Ikon, 29×2.2″, kevlar bead, Rear: Maxxis Ikon, 29×2.2″, kevlar bead |
| Disc Rotors |
Shimano RT10, 180 mm |
Electric Components
| Motor |
Shimano E7000, 60Nm |
|---|---|
| Battery |
Shimano E8010, 504Wh |
| Display |
Shimano SC-E5000A |
| Charger |
Shimano EC-E6002, 2A charging current |
Accessories
| Lights |
Dlight CG-119PG / Dlight CG-404RG, STZVO, STVZO |
|---|---|
| Stand |
Massload CL-KA98 |
