Build
| Frame |
eBIG.NINE LITE III, material: aluminium, 29×2.35″ without fender max./ 29″x2.25″ with fender max. wheelsize, 148x12mm axle standard, intube BB Standard:Â BSA, 73mm, Threaded |
|---|---|
| Fork |
SR Suntour XCM34-Boost LOR DS, 100mm, Tapered, 51mm fork offset, 29×2.4″ max wheelsize Travel:Â 100mm Spring Type:Â Coil |
| Bottom Bracket |
BSA, 73mm, threaded |
| Headset |
MERIDA 8157 |
| Handlebar |
MERIDA EXPERT eTR, 760mm width, 20mm rise |
| Saddle |
MERIDA COMP SL, V-mount |
| Seatpost |
MERIDA EXPERT CC, material: aluminium, 34.9mm diameter, 0mm setback Type:Â Rigid |
| Pedals |
VP VPE-537 |
Groupset
| Rear Derailleur |
Shimano Deore M5120, SGS |
|---|---|
| Crank |
Shimano CRE70-B, 34 teeth |
| Shifters |
Shimano Deore M4100 |
| Cassette |
Shimano M4100, 11-46 teeth, 10 speed |
| Chain |
KMC e10s |
| Brakes |
Shimano MT200, 2 piston Type:Â Hydraulic Disc |
Wheels
| Rims |
MERIDA COMP CC, 20mm inner width, material: aluminium |
|---|---|
| Spokes |
Black stainless |
| Front Hub |
Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock |
| Rear Hub |
Shimano MT400-B, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Tires |
Maxxis Ikon, 29×2.2″, kevlar bead |
| Disc Rotors |
Shimano RT30 / Shimano RTEM300, 180 mm |
Electric Components
| Motor |
Shimano DU-EP600, 85Nm |
|---|---|
| Battery |
Shimano EN806, 630Wh |
| Display |
Shimano SC-EN500 |
Accessories
| Stand |
Massload CL-KA98 |
|---|
