Build
| Frame | eBIG.NINE LITE III, material: aluminium, 29×2.35″ without fender max./ 29″x2.25″ with fender max. wheelsize, 148x12mm axle standard, intube BB Standard: BSA, Threaded |
|---|---|
| Fork | Suntour XCM34-Boost LOR DS, 100mm, Tapered, 51mm fork offset, 29×2.4″ max wheelsize Travel: 100mm Spring Type: Coil |
| Bottom Bracket | BSA, threaded |
| Headset | MERIDA-8157 |
| Stem | MERIDA EXPERT eTRII, material: aluminium, 35mm diameter, 0 stem angle, GoPro & Supernova mount, 50 mm all sizes |
| Handlebar | MERIDA MERIDA TEAM TR, 760mm width, 18mm rise |
| Saddle | MERIDA COMP SL, V-mount |
| Seatpost | MERIDA EXPERT CC, material: aluminium, 34.9mm diameter, 0mm setback Type: Rigid |
| Pedals | VP VPE-537 |
Groupset
| Rear Derailleur | Shimano Deore M5120, SGS |
|---|---|
| Crank | Shimano CRE70-B, 34 teeth |
| Shifters | Shimano Deore M4100 |
| Cassette | Shimano M4100, 11-46 teeth, 10 speed |
| Chain | KMC e10s |
| Brakes | Shimano MT-200, 2 piston Type: Hydraulic Disc |
Wheels
| Rims | MERIDA COMP CC, 20mm inner width, material: aluminium |
|---|---|
| Front Hub | Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Rear Hub | Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Tires | Front: Maxxis Ikon, 29×2.2″, kevlar bead, Rear: Maxxis Ikon, 29×2.2″, kevlar bead |
| Disc Rotors | Shimano RT30 / Shimano RTEM300, 180 mm |
Electric Components
| Motor | Shimano EP6, 85Nm |
|---|---|
| Battery | Shimano EN806, 630Wh |
| Display | Shimano SC-EN500 |
| Charger | Shimano EC-E6002, 2A charging current |
Accessories
| Lights | CG-119PG-BLACK(1) / CG-404RG-BLK |
|---|---|
| Stand | CL-KA98, 29″ |
