Build
| Frame |
eBIG.NINE LITE III, material: aluminium, 29×2.35″ without fender max. / 29×2.25″ with fender max. wheelsize, 148×12 mm axle standard, intube BB Standard:Â BSA, Threaded |
|---|---|
| Fork |
SR Suntour RAIDON34 LOR, Air, 100 mm suspension travel, Tapered, 51 mm fork offset, 29×2.4″ max. wheelsize Travel:Â 100mm Spring Type:Â Air |
| Bottom Bracket |
BSA, threaded |
| Headset |
MERIDA 8157 |
| Stem |
MERIDA EXPERT eTRII, material: aluminium, 35 mm diameter, 0 stem angle, GoPro & Supernova mount, 50 mm all sizes |
| Handlebar |
MERIDA EXPERT eTR, 760 mm width, 20 mm rise |
| Saddle |
PROXIM W400 STN, V-mount adapter, incl. MERIDA minitool |
| Seatpost |
MERIDA EXPERT CC, material: aluminium, 34.9 mm diameter, 0 mm setback Type:Â Rigid |
| Pedals |
VP VPE-527 |
Groupset
| Rear Derailleur |
Shimano XT M8100 Shadow+ 12 |
|---|---|
| Crank |
Shimano CRE80-12-B, 34 teeth |
| Shifters |
Shimano DEORE M6100 |
| Cassette |
Shimano Deore M6100, 10-51 teeth, 12 speed |
| Chain |
KMC e12 |
| Brakes |
Shimano M4100, 4 piston Type:Â Hydraulic Disc |
Wheels
| Rims |
MERIDA COMP CC II, 25 mm inner width, material: aluminium |
|---|---|
| Front Hub |
Shimano TC500-B / Shimano TC600-MS-B, 110×15 mm width front hub, 32 spoke holes, Centerlock, 148×12 mm width rear hub, 32 spoke holes, Centerlock |
| Rear Hub |
Shimano TC500-B / Shimano TC600-MS-B, 110×15 mm width front hub, 32 spoke holes, Centerlock, 148×12 mm width rear hub, 32 spoke holes, Centerlock |
| Tires |
Front: Maxxis Rekon Race, 29×2.35″, fold, TR EXO, Rear: Maxxis Rekon Race, 29×2.35″, fold, TR EXO |
| Disc Rotors |
Shimano RT30, 180 mm |
Electric Components
| Motor |
Shimano EP801, 85Nm |
|---|---|
| Battery |
Trendpower Internal Battery 750Wh |
| Display |
Shimano SC-EN600 |
| Charger |
Simplo EU Charger, 4A |
Accessories
| Lights |
Lezyne E-Bike Power STVZO E115, reverse MERIDA Custom Mount / Chance Good USB CG-214RG |
|---|---|
| Stand |
Massload CL-KA98 |
