Build
| Frame |
eBIG.TOUR LITE IV, material: aluminium, 29×2.35″ without fender max. / 29×2.25″ with fender max. wheelsize, 148×12 mm axle standard, intube BB Standard:Â BSA, Threaded |
|---|---|
| Fork |
SR Suntour XCM34-Boost LOR DS, 100 mm, Tapered, 51 mm fork offset, 29×2.4″ max. wheelsize Travel:Â 100mm Spring Type:Â Coil |
| Bottom Bracket |
BSA, threaded |
| Headset |
MERIDA 8155 |
| Stem |
MERIDA EXPERT CT, material: aluminium, 31.8 mm diameter, adjustable, 90 mm all sizes |
| Handlebar |
MERIDA EXPERT CC, material: aluminium, 720 mm width, 10 mm rise |
| Saddle |
MERIDA EXPERT TK, V-mount |
| Seatpost |
MERIDA EXPERT CC, material: aluminium, 34.9 mm diameter, 0 mm setback Type:Â Rigid |
| Pedals |
VP VPE-537 |
Groupset
| Rear Derailleur |
Shimano CUES U6000, GS |
|---|---|
| Crank |
Shimano CRE70-B, 34 teeth |
| Shifters |
Shimano CUES U6000 |
| Cassette |
Shimano LG300, 11-48 teeth, 10 speed |
| Chain |
Shimano LG500 |
| Brakes |
Shimano MT-200, 2 piston Type:Â Hydraulic Disc |
Wheels
| Rims |
MERIDA COMP CC II, 25 mm inner width, material: aluminium |
|---|---|
| Front Hub |
Shimano TC500-B / Shimano TC500-HM-B, 110×15 mm width front hub, 32 spoke holes, Centerlock, 148×12 mm width rear hub, 32 spoke holes, Centerlock |
| Rear Hub |
Shimano TC500-B / Shimano TC500-HM-B, 110×15 mm width front hub, 32 spoke holes, Centerlock, 148×12 mm width rear hub, 32 spoke holes, Centerlock |
| Tires |
Front: Kenda Booster, 29×2.2″, wire, Rear: Kenda Booster, 29×2.2″, wire |
| Disc Rotors |
Shimano RT30, 180 mm |
Electric Components
| Motor |
Shimano EP6, 85Nm |
|---|---|
| Battery |
Shimano EN806, 630Wh |
| Display |
Shimano SC-EN500 |
| Charger |
Shimano EC-E6002, 2A charging current |
Accessories
| Lights |
Lezyne E-Bike Hecto STVZO E65 / Spanninga Co mmuter GLOW XE |
|---|---|
| Fenders |
Sunnywheel SW-FA311-65A/ SW-FA311-65E1 |
| Racks |
MERIDA MA008-1 w/spring clamp |
| Lock |
Abus 5650 LH-3 lock |
| Stand |
Massload CL-KA98 |
