Build
| Frame | eBIG.TOUR LITE III, material: aluminium, 29×2.35″ without fender max./ 29″x2.25″ with fender max. wheelsize, 148x12mm axle standard, MUK 37 Hanger BB Standard: BSA, Threaded |
|---|---|
| Fork | SR Suntour XCR34 LOR DS, Air Boost, 100mm, Tapered, 51mm fork offset, 29×2.4″ max wheelsize Travel: 100mm Spring Type: Air |
| Bottom Bracket | BSA, threaded |
| Headset | MERIDA 8155 |
| Stem | MERIDA EXPERT CT, material: aluminium, 31.8mm diameter, adjustable, 90 mm |
| Handlebar | MERIDA EXPERT CC, material: aluminium, 720mm width, 10mm rise |
| Saddle | MERIDA EXPERT TK, V-mount |
| Seatpost | MERIDA EXPERT CC, material: aluminium, 34.9mm diameter, 0mm setback Type: Rigid |
| Pedals | VP VPE-537 |
Groupset
| Rear Derailleur | Shimano Deore RDM5100 11 |
|---|---|
| Crank | Shimano CRE70-B, 34 teeth |
| Shifters | Shimano Deore M5100 |
| Cassette | Shimano M5100, 11-51 teeth, 11 speed |
| Chain | KMC e11S EPT |
| Brakes | Shimano M4100, 4 piston, 2 piston Type: Hydraulic Disc |
Wheels
| Rims | MERIDA COMP CC, 20mm inner width, material: aluminium |
|---|---|
| Front Hub | Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Rear Hub | Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Tires | Front: Kenda Booster, 29×2.2″, wire, Rear: Kenda Booster, 29×2.2″, wire |
| Disc Rotors | Shimano RT30 / Shimano RTEM300, 180 mm |
Electric Components
| Motor | Shimano EP8, 85Nm |
|---|---|
| Battery | Shimano E8036, 630Wh |
| Display | Shimano SC-E5003A |
| Charger | Shimano EC-E6002, 2A charging current |
Accessories
| Lights | Lezyne E-Bike Power E115 / Spanninga Commuter Glow XE, StVZO, X-Lock stem mount, STVZO, integrated in MERIDA MIK HD carrier |
|---|---|
| Fenders | Sunnywheel SW-FA311-65A/ SW-FA311-65E1 |
| Racks | MERIDA MA008-1, spring clamp, Spanninga GLOW XE rear light |
| Lock | Abus 5650 LH-3 lock |
| Stand | Massload CL-KA98 |
