Build
| Frame |
eBIG.TOUR LITE III, material: aluminium, 29×2.35″ without fender max./ 29″x2.25″ with fender max. wheelsize, 148x12mm axle standard, intube BB Standard:Â BSA, Threaded |
|---|---|
| Fork |
Suntour XCR34 LOR DS, Air Boost, 100mm, Tapered, 51mm fork offset, 29×2.4″ max wheelsize Travel:Â 100mm Spring Type:Â Air |
| Bottom Bracket |
BSA, threaded |
| Headset |
MERIDA-8155 (for the steerer 1-1/8″~1.5″) |
| Stem |
MERIDA EXPERT CT, material: aluminium, 31.8mm diameter, adjustable, 90 mm all sizes |
| Handlebar |
MERIDA EXPERT CC, material: aluminium, 720mm width, 10mm rise |
| Saddle |
MERIDA EXPERT TK, V-mount |
| Seatpost |
MERIDA EXPERT CC, material: aluminium, 34.9mm diameter, 0mm setback Type:Â Rigid |
| Pedals |
VP VPE-537 |
Groupset
| Rear Derailleur |
Shimano Deore RDM5100 11 |
|---|---|
| Crank |
Shimano CRE70-B, 34 teeth |
| Shifters |
Shimano Deore M5100 11 |
| Cassette |
Shimano M5100, 11-51 teeth, 11 speed |
| Chain |
KMC e11S EPT |
| Brakes |
Shimano M4100, 4 piston, 2 piston Type:Â Hydraulic Disc |
Wheels
| Rims |
MERIDA COMP CC, 20mm inner width, material: aluminium |
|---|---|
| Front Hub |
Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Rear Hub |
Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Tires |
Front: KENDA Booster, 29×2.2″, wire, Rear: KENDA Booster, 29×2.2″, wire |
| Disc Rotors |
Shimano RT30 / Shimano RTEM300, 180 mm |
Electric Components
| Motor |
Shimano EP6, 85Nm |
|---|---|
| Battery |
Shimano EN806, 630Wh |
| Display |
Shimano SC-EN600 |
| Charger |
Shimano EC-E6002, 2A charging current |
Accessories
| Lights |
LEZYNE E-BIKE POWER STVZO E115, X-Lock stem mount / Spanninga Commuter GLOW XE |
|---|---|
| Fenders |
Sunnywheel SW-FA311-65A/ SW-FA311-65E1 |
| Racks |
MERIDA MA008-1 w/spring clamp + Spanninga GLOW XE |
| Lock |
Abus 5650 LH-3 lock |
| Stand |
CL-KA98, 29″ |
