Build
| Frame | eBIG.TOUR LITE IV, material: aluminium, 29×2.35″ without fender max. / 29×2.25″ with fender max. wheelsize, 148×12 mm axle standard, intube BB Standard: BSA, Threaded |
|---|---|
| Fork | SR Suntour XCR34 LOR DS, Air Boost, 100 mm, Tapered, 51 mm fork offset, 29×2.4″ max. wheelsize Travel: 100mm Spring Type: Air |
| Bottom Bracket | BSA, threaded |
| Headset | MERIDA 8155 |
| Stem | MERIDA EXPERT CT, material: aluminium, 31.8 mm diameter, adjustable, 90 mm all sizes |
| Handlebar | MERIDA EXPERT CC, material: aluminium, 720 mm width, 10 mm rise |
| Saddle | MERIDA EXPERT TK, V-mount |
| Seatpost | MERIDA EXPERT CC, material: aluminium, 34.9 mm diameter, 0 mm setback Type: Rigid |
| Pedals | VP VPE-537 |
Groupset
| Rear Derailleur | SRAM NX Eagle |
|---|---|
| Crank | Samox EMA04, 34 teeth |
| Shifters | SRAM NX Eagle 12 |
| Cassette | SRAM PG-1210 Eagle, 10-50 teeth, 12 speed |
| Chain | SRAM SX Eagle |
| Brakes | SRAM DB8, 4 piston Type: Hydraulic Disc |
Wheels
| Rims | MERIDA COMP CC II, 25 mm inner width, material: aluminium |
|---|---|
| Front Hub | Novatec SL-TEAM D041SB-B15 / Novatec SL-TEAM D462SB-S3S-B12-11S, 110×15 mm width front hub, 32 spoke holes, 6 bolt, 148×12 mm width rear hub, 36 spoke holes, 6 bolt |
| Rear Hub | Novatec SL-TEAM D041SB-B15 / Novatec SL-TEAM D462SB-S3S-B12-11S, 110×15 mm width front hub, 32 spoke holes, 6 bolt, 148×12 mm width rear hub, 36 spoke holes, 6 bolt |
| Tires | Front: Kenda Booster, 29×2.2″, wire, Rear: Kenda Booster, 29×2.2″, wire |
| Disc Rotors | SRAM CenterLine, 180 mm |
Electric Components
| Motor | Shimano EP6, 85Nm |
|---|---|
| Battery | Trendpower Internal Battery 750Wh |
| Display | Shimano SC-EN600 |
| Charger | Simplo EU Charger, 4A |
Accessories
| Lights | Lezyne E-Bike Power STVZO E115 / Spanninga Co mmuter GLOW XE |
|---|---|
| Fenders | Sunnywheel SW-FA311-65A/ SW-FA311-65E1 |
| Racks | MERIDA MA008-1 w/spring clamp |
| Lock | Abus 5650 LH-3 lock |
| Stand | Massload CL-KA98 |
