Build
| Frame | eONE-FORTY LITE III, material: aluminium, 133mm suspension travel, 27.5×2.8″ max. wheelsize, 148x12mm axle standard, intube BB Standard: BSA, 73mm, Threaded |
|---|---|
| Fork | Suntour XCR34 LOR DS, Air Boost, 140mm, Tapered, 51mm fork offset, 29×2.4″ max wheelsize Travel: 140mm Spring Type: Air |
| Shock | SUNTOUR RS-EDGE-TR-LO-R8-M6, lockout Travel: 133mm |
| Bottom Bracket | BSA, 73mm, threaded |
| Headset | MERIDA-8152 |
| Stem | MERIDA EXPERT eTR II, material: aluminium, 35mm diameter, 0 stem angle, GoPro & Supernova mount, 50 mm all sizes |
| Handlebar | MERIDA EXPERT eTR, 780mm width, 20mm rise |
| Saddle | MERIDA COMP SL, V-mount |
| Seatpost | MERIDA COMP TR, 30.9mm diameter, 0mm setback, M 100mm travel seatpost – L/XL 125mm travel seatpost – XXL 150mm travel seatpost Type: Dropper |
| Pedals | VP VPE-537 |
Groupset
| Rear Derailleur | Shimano Deore RDM5120 10 |
|---|---|
| Crank | Shimano CRE70-B, 34 teeth |
| Shifters | Shimano SL -MT500-IL / Shimano Deore M4100 |
| Cassette | Shimano M4100, 11-46 teeth, 10 speed |
| Chain | KMC e10s |
| Brakes | Shimano M42040 / Shimano M4100, 4 piston, 2 piston Type: Hydraulic Disc |
Wheels
| Rims | MERIDA COMP TR, 29mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included) |
|---|---|
| Front Hub | Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Rear Hub | Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Tires | Front: MAXXIS REKON, 29×2.4″, wire, DUAL, Rear: MAXXIS REKON, 27.5×2.6″, wire, EXO |
| Disc Rotors | Shimano RT30 / Shimano RTEM300, 203 mm, 180 mm |
Electric Components
| Motor | Shimano EP6, 85Nm |
|---|---|
| Battery | Shimano EN806, 630Wh Shimano EN805 504Wh for XS only |
| Display | Shimano SC-EN600 |
| Charger | Shimano EC-E6002, 2A charging current |
Accessories
| Lights | CG-119PG-BLACK(1) / CG-404RG-BLK |
|---|---|
| Fenders | C093-02F + C093-02R |
