Build
| Frame | eONE-FORTY LITE III, material: aluminium, 133 mm suspension travel, 27.5×2.8″ max. wheelsize, 148×12 mm axle standard, intube BB Standard: BSA, 73mm, Threaded |
|---|---|
| Fork | SR Suntour XCR34 LOR DS, Air Boost, 140 mm, Tapered, 51 mm fork offset, 29×2.4″ max. wheelsize Travel: 140mm Spring Type: Air |
| Shock | SR Suntour Edge, platform Travel: 133mm |
| Bottom Bracket | BSA, 73mm, threaded |
| Headset | MERIDA 8152 |
| Stem | MERIDA EXPERT eTR II, material: aluminium, 35 mm diameter, 0 stem angle, GoPro & Supernova mount, 40 mm all sizes |
| Handlebar | MERIDA EXPERT eTR, 780 mm width, 20 mm rise |
| Saddle | MERIDA COMP SL, V-mount |
| Seatpost | MERIDA COMP TR, 30.9 mm diameter, 0 mm setback, M 100 mm travel seatpost – L/XL 125 mm travel seatpost – XXL 150 mm travel seatpost Type: Dropper |
| Pedals | VP VPE-537 |
Groupset
| Rear Derailleur | Shimano CUES U6000, GS |
|---|---|
| Crank | Shimano CRE70-B, 34 teeth |
| Shifters | Shimano SL -MT500-IL / Shimano CUES U6000 |
| Cassette | Shimano LG300, 11-48 teeth, 10 speed |
| Chain | Shimano LG500 |
| Brakes | Shimano MT420 / Shimano M4100, 4 piston, 2 piston Type: Hydraulic Disc |
Wheels
| Rims | MERIDA COMP TR II, 28 mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included) |
|---|---|
| Spokes | Black stainless |
| Front Hub | Shimano TC500-B / Shimano TC500-HM-B, 110×15 mm width front hub, 32 spoke holes, Centerlock, 148×12 mm width rear hub, 32 spoke holes, Centerlock |
| Rear Hub | Shimano TC500-B / Shimano TC500-HM-B, 110×15 mm width front hub, 32 spoke holes, Centerlock, 148×12 mm width rear hub, 32 spoke holes, Centerlock |
| Tires | Front: Maxxis Rekon, 29×2.4″, wire, DUAL, Rear: Maxxis Rekon, 27.5×2.6″, wire, EXO |
| Disc Rotors | Shimano RT30 / Shimano RT-EM300, 203 mm |
Electric Components
| Motor | Shimano EP6, 85Nm |
|---|---|
| Battery | Shimano EN806 630Wh, Shimano EN805 504Wh for XS only |
| Display | Shimano SC-EN600 |
| Charger | Shimano EC-E6002, 2A charging current |
Accessories
| Lights | Chance Good 119PG / Chance Good 404RG |
|---|---|
| Fenders | Sunnywheel C093-02F + C093-02R |
