Build
| Frame |
eONE-FORTY LITE IV, material: aluminium, 143 mm suspension travel, 27.5×2.8″ max. wheelsize, 148×12 mm axle standard, intube BB Standard:Â BSA, 73mm, Threaded |
|---|---|
| Fork |
SR Suntour Zeron 36 X, platform |
| Shock |
SR Suntour Edge Plus, platform Travel:Â 143mm |
| Bottom Bracket |
BSA, 73mm, threaded |
| Headset |
Acros ICR MERIDA EXTERNAL neck w/ Blocklock |
| Handlebar |
MERIDA EXPERT eTR, 780 mm width, 20 mm rise |
| Saddle |
MERIDA EXPERT SL, V-mount, incl. MERIDA minitool |
| Seatpost |
MERIDA EXPERT TR II, 34.9 mm diameter, 0 mm setback, XS: 125 mm travel seatpost – S: 150 mm travel seatpost – M/L/XL: 200 mm travel seatpost Type:Â Dropper |
| Pedals |
VP VPE-527 |
Groupset
| Rear Derailleur |
Shimano CUES U6000, GS |
|---|---|
| Crank |
FSA 1x Steel Megatooth Chainring, 36 teeth |
| Shifters |
Shimano SL -MT500-IL |
| Cassette |
Shimano LG400, 11-48 teeth, 10 speed |
| Chain |
Shimano LG500 |
| Brakes |
Shimano MT420, 4 piston Type:Â Hydraulic Disc |
Wheels
| Rims |
MERIDA COMP TR II, 28 mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included) |
|---|---|
| Spokes |
Black stainless |
| Front Hub |
Shimano TC500-B, 110×15 mm width front hub, 32 spoke holes, Centerlock |
| Rear Hub |
Shimano TC500-HM-B, 148×12 mm width rear hub, 32 spoke holes, Centerlock |
| Tires |
Maxxis Rekon, 29×2.4″, fold, 3C EXO MaxxTerra |
| Disc Rotors |
Shimano RT64 / Shimano RT-EM600, 203 mm |
Electric Components
| Motor |
Shimano EP801, 85Nm |
|---|---|
| Battery |
Trendpower Internal Battery 750Wh |
| Display |
Shimano SC-EN600 |
Accessories
| Fenders |
Winning EOF-204 |
|---|---|
| Racks |
MERIDA MIK HD Carrier with Spring clip & Spanninga rear light |
| Stand |
Atranvelo ED-100-PC |
