Build
| Frame |
eONE-FORTY LITE III, material: aluminium, 133mm suspension travel, 27.5×2.8″ max. wheelsize, 148x12mm axle standard, MUK 37 Hanger BB Standard:Â BSA, 73mm, Threaded |
|---|---|
| Fork |
Marzocchi Z2 eMTB+, Air, 140mm suspension travel, Tapered, 51mm fork offset, 29×2.6″ max wheelsize Travel:Â 140mm Spring Type:Â Air |
| Shock |
SR Suntour EDGE, lockout Travel:Â 133mm |
| Bottom Bracket |
BSA, 73mm, threaded |
| Headset |
MERIDA 8152 |
| Stem |
MERIDA EXPERT eTRII, material: aluminium, 35mm diameter, 0 stem angle, GoPro & Supernova mount, 50 mm |
| Handlebar |
MERIDA EXPERT eTR, 780mm width, 20mm rise |
| Saddle |
MERIDA COMP SL, V-mount |
| Seatpost |
MERIDA COMP TR, 30.9mm diameter, 0mm setback, S/M 100mm travel seatpost – L/XL 125mm travel seatpost – XXL 150mm travel seatpost Type:Â Dropper |
| Pedals |
VP VPE-537 |
Groupset
| Rear Derailleur |
Shimano Deore RDM5100 11 |
|---|---|
| Crank |
Shimano CRE70-B, 34 teeth |
| Shifters |
Shimano SL -MT500-IL / Shimano Deore M5100 |
| Cassette |
Shimano M5100, 11-51 teeth, 11 speed |
| Chain |
KMC e11S EPT |
| Brakes |
Shimano M4100, 4 piston Type:Â Hydraulic Disc |
Wheels
| Rims |
MERIDA COMP TR, 29mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included) |
|---|---|
| Spokes |
Black stainless |
| Front Hub |
Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Rear Hub |
Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Tires |
Front: Maxxis Rekon, 29×2.4″, wire, DUAL, Rear: Maxxis Rekon, 27.5×2.6″, wire, EXO |
| Disc Rotors |
Shimano RT30 / Shimano RTEM300, 203 mm |
Electric Components
| Motor |
Shimano EP8, 85Nm |
|---|---|
| Battery |
Shimano E8036 630Wh / Shimano E8035 504Wh for S only |
| Display |
Shimano SC-E5003A |
| Charger |
Shimano EC-E6002, 2A charging current |
Accessories
| Lights |
Lezyne E-Bike Power E115 / Dlight CG-214RG, StVZO, reverse MERIDA Custom Mount, STVZO, USB |
|---|---|
| Fenders |
C093-02F + C093-02R |
