Build
| Frame | eONE-FORTY LITE IV, material: aluminium, 143 mm suspension travel, 27.5×2.8″ max. wheelsize, 148×12 mm axle standard, intube BB Standard: BSA, 73mm, Threaded |
|---|---|
| Fork | SR Suntour AION X 36 Boost, Air, 150 mm suspension travel, Tapered, 44 mm fork offset, 29×2.5″ max. wheelsize Travel: 150mm Spring Type: Air |
| Shock | Rock Shox Super Deluxe Select Travel: 143mm |
| Bottom Bracket | BSA, 73mm, threaded |
| Headset | Acros ICR MERIDA EXTERNAL neck w/ Blocklock |
| Stem | MERIDA EXPERT eTR II, material: aluminium, 35 mm diameter, 0 stem angle, Supernova mount, 40 mm all sizes |
| Handlebar | MERIDA EXPERT eTR, 780 mm width, 20 mm rise |
| Saddle | MERIDA EXPERT SL, V-mount, incl. MERIDA minitool |
| Seatpost | MERIDA EXPERT TR II, 34.9 mm diameter, 0 mm setback, XS: 125 mm travel seatpost – S: 150 mm travel seatpost – M/L/XL: 200 mm travel seatpost Type: Dropper |
| Pedals | VP VPE-527 |
Groupset
| Rear Derailleur | SRAM NX Eagle |
|---|---|
| Crank | FSA 1x Steel Megatooth Chainring, 36 teeth |
| Shifters | Limotec RM10 (For SRAM mmX) / SRAM NX Eagle 12 |
| Cassette | SRAM PG-1210 Eagle, 10-50 teeth, 12 speed |
| Chain | SRAM SX Eagle |
| Brakes | SRAM DB8, 4 piston Type: Hydraulic Disc |
Wheels
| Rims | MERIDA EXPERT TR II, 110×15 mm width front hub, 148×12 mm width rear hub, 28 mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included), 29″ |
|---|---|
| Spokes | Black stainless |
| Front Hub | Novatec SL-TEAM D041SB-B15 / Novatec SL-TEAM D462SB-S3S-B12-11S, 110×15 mm width front hub, 32 spoke holes, 6 bolt, 148×12 mm width rear hub, 32 spoke holes, 6 bolt |
| Rear Hub | Novatec SL-TEAM D041SB-B15 / Novatec SL-TEAM D462SB-S3S-B12-11S, 110×15 mm width front hub, 32 spoke holes, 6 bolt, 148×12 mm width rear hub, 32 spoke holes, 6 bolt |
| Tires | Front: Maxxis Rekon, 29×2.4″, fold, 3C EXO MaxxTerra |
| Disc Rotors | SRAM CenterLine, 200 mm |
Electric Components
| Motor | Shimano EP801, 85Nm |
|---|---|
| Battery | Trendpower Internal Battery 750Wh |
| Display | Shimano SC-EN600 |
| Charger | Trendpower EU Charger, 4A |
Accessories
| Lights | Lezyne E-Bike Power STVZO E115, reverse MERIDA Custom Mount / Chance Good USB CG-214RG |
|---|---|
| Fenders | Winning EOF-204 |
