Build
| Frame |
eONE-FORTY CFA II, material: carbon, 133mm suspension travel, 27.5×2.8″ max. wheelsize, 148x12mm axle standard, intube, max. 630 Wh BB Standard:Â BSA, 73mm, Threaded |
|---|---|
| Fork |
FOX Rhythm 34 Float eMTB+, Air, 140mm suspension travel, Tapered, 51mm fork offset, 29×2.5″ max wheelsize Travel:Â 140mm Spring Type:Â Air |
| Shock |
FOX Performance Float DPS, lockout Travel:Â 133mm |
| Bottom Bracket |
BSA, 73mm, threaded |
| Headset |
MERIDA 8152 |
| Handlebar |
MERIDA EXPERT eTR, 780mm width, 20mm rise |
| Saddle |
MERIDA EXPERT CC, V-mount |
| Seatpost |
MERIDA EXPERT TR, 30.9mm diameter, 0mm setback, S 100mm travel seatpost – S/M 125mm travel seatpost – L 150mm travel seatpost – XL/XXL 170mm travel seatpost Type:Â Dropper |
| Pedals |
VP VPE-527 |
Groupset
| Rear Derailleur |
Shimano XT RDM8130 Shadow+ 11 |
|---|---|
| Crank |
Shimano CRE80-B, 34 teeth |
| Shifters |
Shimano SL -MT500-IL |
| Cassette |
Shimano LG600, 11-50 teeth, 11 speed |
| Chain |
CNLG500 |
| Brakes |
Shimano SLX, 4 piston Type:Â Hydraulic Disc |
Wheels
| Rims |
MERIDA EXPERT TR, 29mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included) |
|---|---|
| Spokes |
Black stainless |
| Front Hub |
Shimano XT, 110x15mm width front hub, 32 spoke holes, Centerlock |
| Rear Hub |
Shimano XT, 148x12mm width rear hub, 36 spoke holes, Centerlock |
| Tires |
Continental Trail King, 29×2.4 “, fold, BlackChili, ProTection Apex, TR |
Electric Components
| Motor |
Shimano EP8, 85Nm |
|---|---|
| Battery |
Shimano E8036 630Wh / Shimano E8035 504Wh for S only |
| Display |
Shimano SC-E7000 |
Accessories
| Fenders |
C093-02F + C093-02R |
|---|
