Build
| Frame |
eONE-SIXTY CF4 III, material: carbon, 174 mm suspension travel, 29×2,6″ max. wheelsize, 148×12 mm axle standard, intube BB Standard:Â STEPS, Press Fit Hanger Standard:Â UDH |
|---|---|
| Fork |
Fox 38 Factory eMTB+, Air, 170 mm suspension travel, Tapered, 44 mm fork offset, 29×2.6″ max. wheelsize Travel:Â 170mm Spring Type:Â Air |
| Shock |
Fox Float X2 Factory, 2 Pos Lever Travel:Â 174mm |
| Bottom Bracket |
STEPS, press-fit |
| Headset |
Acros ICR MERIDA INTEGRATED neck w/ Blocklock |
| Stem |
MERIDA EXPERT eTR II, material: aluminium, 35 mm diameter, 0 stem angle, Supernova mount, 40 mm all sizes |
| Handlebar |
MERIDA TEAM TR II, material: carbon, 800 mm width, 20 mm rise |
| Saddle |
PROXIM W400 T2.0, V-mount adapter, incl. MERIDA minitool |
| Seatpost |
MERIDA TEAM TR II, 34.9 mm diameter, 0 mm setback, all sizes 30-230 mm travel seatpost Type:Â Dropper |
| Pedals |
VP VPE-527 |
Groupset
| Rear Derailleur |
SRAM XX Eagle Transmission AXS |
|---|---|
| Crank |
SRAM XX Eagle Transmission E-MTB for Steps, 36 teeth |
| Shifters |
SRAM AXS Pod Controller |
| Cassette |
SRAM XX Eagle Transmission, 10-52, 12 speed |
| Chain |
SRAM XX Eagle Transmission, Flattop |
| Brakes |
SRAM Code Ultimate Stealth, 4 piston Type:Â Hydraulic Disc |
Wheels
| Rims |
DT Swiss Spline HXC1501 spline 30 boost, 110×15 mm width front hub, 148×12 mm width rear hub, 30 mm inner width, Centerlock, microspline, material: carbon, Tubeless ready (tubeless tape and valves included) |
|---|---|
| Front Hub |
MERIDA EXPERT TR, including removeable lever, 6/4 mm allen key |
| Rear Hub |
MERIDA EXPERT TR, including removeable lever, 6/4 mm allen key |
| Tires |
Front: Maxxis Assegai, 29×2.5″, fold, TR EXO+ 3C MaxxGrip, Rear: Maxxis DHR II, 27.5×2.4″, fold, 3C DD MaxxTerra |
| Disc Rotors |
SRAM HS2, 220 mm, 200 mm |
Electric Components
| Motor |
Shimano EP801, 85Nm |
|---|---|
| Battery |
Trendpower Internal Battery 600 Wh |
| Display |
Shimano SC-EM800 |
| Charger |
Trendpower EU Charger, 4A |
Accessories
| Lights |
Lezyne E-Bike Power STVZO E115, reverse MERIDA Custom Mount / Lezyne LED Femto USB STVZO |
|---|---|
| Fenders |
C093-02F + C093-02R |
