Build
| Frame |
eONE-SIXTY LITE III, material: aluminium, 150 mm suspension travel, 27.5×2.8″ max. wheelsize, 148×12 mm axle standard, intube BB Standard:Â BSA, 73mm, Threaded |
|---|---|
| Fork |
Rock Shox 35 Gold, Air, 160 mm suspension travel, Tapered, 44 mm fork offset, 29×2.8″ max. wheelsize Travel:Â 160mm Spring Type:Â Air |
| Shock |
Rock Shox Deluxe Select+, platform Travel:Â 150mm |
| Bottom Bracket |
BSA, 73mm, threaded |
| Headset |
MERIDA 8152 |
| Stem |
MERIDA EXPERT eTR II, material: aluminium, 35 mm diameter, 0 stem angle, Supernova mount, 40 mm all sizes |
| Handlebar |
MERIDA EXPERT eTR, 780 mm width, 20 mm rise |
| Saddle |
MERIDA COMP SL, V-mount |
| Seatpost |
MERIDA COMP TR, 30.9 mm diameter, 0 mm setback, XS/S 100 mm travel seatpost – M/L 125 mm travel seatpost – XL 150 mm travel seatpost Type:Â Dropper |
| Pedals |
VP VPE-537 |
Groupset
| Rear Derailleur |
SRAM NX Eagle |
|---|---|
| Crank |
Samox EMA04, 34 teeth |
| Shifters |
Limotech RM10 (For SRAM mmX) / SRAM NX Eagle 12 |
| Cassette |
SRAM PG-1210 Eagle, 10-50 teeth, 12 speed |
| Chain |
SRAM SX Eagle |
| Brakes |
SRAM DB8, 4 piston Type:Â Hydraulic Disc |
Wheels
| Rims |
MERIDA COMP TR II, 28 mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included) |
|---|---|
| Spokes |
Black stainless |
| Front Hub |
Novatec SL-TEAM D041SB-B15 / Novatec SL-TEAM D462SB-S3S-B12-11S, 110×15 mm width front hub, 32 spoke holes, 6 bolt, 148×12 mm width rear hub, 32 spoke holes, 6 bolt |
| Rear Hub |
Novatec SL-TEAM D041SB-B15 / Novatec SL-TEAM D462SB-S3S-B12-11S, 110×15 mm width front hub, 32 spoke holes, 6 bolt, 148×12 mm width rear hub, 32 spoke holes, 6 bolt |
| Tires |
Front: Kenda Regolith, 29×2.4″, wire, Rear: Kenda Regolith, 27.5×2.6″, wire |
| Disc Rotors |
SRAM CenterLine, 200 mm |
Electric Components
| Motor |
Shimano EP6, 85Nm |
|---|---|
| Battery |
Shimano EN806 630Wh, Shimano EN805 504Wh for XS only |
| Display |
Shimano SC-EN600 |
| Charger |
Shimano EC-E6002, 2A charging current |
Accessories
| Lights |
Lezyne E-Bike Power STVZO E115, reverse MERIDA Custom Mount / Chance Good USB CG-214RG |
|---|---|
| Fenders |
C093-02F + C093-02R |
