Build
Frame |
eONE-SIXTY CFA II, material: carbon, 150mm suspension travel, 27.5×2.8″ max. wheelsize, 148x12mm axle standard, intube, max. 630 Wh BB Standard:Â BSA, 73mm, Threaded |
---|---|
Fork |
Marzocchi Z1 Ebike+, Air, 160mm suspension travel, Tapered, 51mm fork offset, 29×2.6″ max wheelsize Travel:Â 160mm Spring Type:Â Air |
Shock |
FOX Float DPX2 Performance, platform Travel:Â 150mm |
Bottom Bracket |
BSA, 73mm, threaded |
Headset |
MERIDA-8152 |
Handlebar |
MERIDA EXPERT eTR, 780mm width, 20mm rise |
Saddle |
MERIDA EXPERT CC, V-mount |
Seatpost |
MERIDA EXPERT TR, 30.9mm diameter, 0mm setback, XS 125mm travel seatpost – S/M 150mm travel seatpost – L/XL 170mm travel seatpost Type:Â Dropper |
Pedals |
VP VPE-527 |
Groupset
Rear Derailleur |
Shimano XT RDM8130 Shadow+ 11 |
---|---|
Crank |
Shimano CRE80-B, 34 teeth, Shimano FCEM600 |
Shifters |
Shimano SL -MT500-IL |
Cassette |
Shimano LG600, 11-50 teeth, 11 speed |
Chain |
CNLG500 |
Brakes |
Shimano SLX, 4 piston Type:Â Hydraulic Disc |
Wheels
Rims |
MERIDA EXPERT TR, 29mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included) |
---|---|
Spokes |
Black stainless |
Front Hub |
Shimano XT, 110x15mm width front hub, 32 spoke holes, Centerlock |
Rear Hub |
Shimano XT, 148x12mm width rear hub, 36 spoke holes, Centerlock |
Tires |
Maxxis Assegai, 29×2.5 “, fold, TR EXO+ 3C MaxxGrip |
Disc Rotors |
Shimano RT64 / Shimano RTEM600, 203 mm |
Electric Components
Motor |
Shimano DU-EP600, 85Nm |
---|---|
Battery |
Shimano EN806 |
Display |
Shimano SC-EN600 |
Accessories
Fenders |
C093-02F + C093-02R |
---|
