Build
| Frame | eONE-SIXTY LITE IV, material: aluminium, 174 mm suspension travel, 29×2.6″ max. wheelsize, 148×12 mm axle standard, intube BB Standard: BSA, 73mm, Threaded |
|---|---|
| Fork | Rock Shox ZEB Select, Air, 170 mm suspension travel, Tapered, 44 mm fork offset, 29×2.8″ max. wheelsize Travel: 170mm Spring Type: Air |
| Shock | Rock Shox Super Deluxe Select Travel: 174mm |
| Bottom Bracket | BSA, 73mm, threaded |
| Headset | Acros ICR MERIDA EXTERNAL neck w/ Blocklock |
| Stem | MERIDA EXPERT eTR II, material: aluminium, 35 mm diameter, 0 stem angle, Supernova mount, 40 mm all sizes |
| Handlebar | MERIDA EXPERT eTR, 780 mm width, 20 mm rise |
| Saddle | PROXIM W400 STN, V-mount adapter, incl. MERIDA minitool |
| Seatpost | MERIDA TEAM TR II, 34.9 mm diameter, 0 mm setback, all sizes 30-230 mm travel seatpost Type: Dropper |
| Pedals | VP VPE-527 |
Groupset
| Rear Derailleur | Shimano XT M8130 LinkGlide 11 |
|---|---|
| Crank | FSA 1x Steel Megatooth Chainring, 36 teeth |
| Shifters | Shimano SL -MT500-IL / Shimano XT M8130 |
| Cassette | Shimano LG700, 11-50 teeth, 11 speed |
| Chain | Shimano LG500 |
| Brakes | Shimano XT, 4 piston Type: Hydraulic Disc |
Wheels
| Rims | MERIDA EXPERT TR II, 110×15 mm width front hub, 148×12 mm width rear hub, 28 mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included), front 29″, rear 27.5″ |
|---|---|
| Spokes | Black stainless |
| Front Hub | Shimano XT, 110×15 mm width front hub, 32 spoke holes, Centerlock, 148×12 mm width rear hub, 32 spoke holes, Centerlock |
| Rear Hub | Shimano XT, 110×15 mm width front hub, 32 spoke holes, Centerlock, 148×12 mm width rear hub, 32 spoke holes, Centerlock |
| Tires | Front: Maxxis Assegai, 29×2.5″, fold, TR EXO+ 3C MaxxGrip, Rear: Maxxis DHR II, 27.5×2.4″, fold, 3C DD MaxxTerra |
| Disc Rotors | Shimano RT64 / Shimano RT-EM600, 220 mm, 203 mm |
Electric Components
| Motor | Shimano EP801, 85Nm |
|---|---|
| Battery | Trendpower Internal Battery 750Wh |
| Display | Shimano SC-EM800 |
| Charger | Trendpower EU Charger, 4A |
Accessories
| Lights | Lezyne E-Bike Power STVZO E115, reverse MERIDA Custom Mount / Lezyne LED Femto USB STVZO |
|---|---|
| Fenders | C093-02F + C093-02R |
