Build
| Frame | eONE-SIXTY CFA II, material: carbon, 150mm suspension travel, 27.5×2.8″ max. wheelsize, 148x12mm axle standard, intube, max. 630 Wh BB Standard: BSA, 73mm, Threaded |
|---|---|
| Fork | FOX 38 Elite eMTB+ Air, 160mm suspension travel, Tapered, 51mm fork offset, 29×2.6″ max wheelsize Travel: 160mm Spring Type: Air |
| Shock | FOX Float X Performance Elite, platform Travel: 150mm |
| Bottom Bracket | BSA, 73mm, threaded |
| Headset | MERIDA-8152 |
| Stem | MERIDA EXPERT eTR II, material: aluminium, 35mm diameter, 0 stem angle, Supernova mount, 40 mm all sizes |
| Handlebar | MERIDA EXPERT eTR, 780mm width, 20mm rise |
| Saddle | MERIDA EXPERT CC, V-mount |
| Seatpost | MERIDA EXPERT TR, 30.9mm diameter, 0mm setback, XS 100mm travel seatpost – S 125mm travel seatpost – M 150mm travel seatpost – L/XL 170mm travel seatpost Type: Dropper |
| Pedals | VP VPE-527 |
Groupset
| Rear Derailleur | Shimano XT RDM8130 Shadow+ 11 |
|---|---|
| Crank | Shimano CRE80-B, 34 teeth |
| Shifters | Shimano SL -MT800-IL / Shimano XT M8130 11 |
| Cassette | Shimano LG600, 11-50 teeth, 11 speed |
| Chain | CNLG500 |
| Brakes | Shimano XT, 4 piston Type: Hydraulic Disc |
Wheels
| Rims | DT Swiss Spline HX1501 ONE 30 boost, 110x15mm width front hub, 148x12mm width rear hub, 30mm inner width, Centerlock, material: aluminium, Tubeless ready (tubeless tape and valves included) |
|---|---|
| Front Hub | MERIDA EXPERT TR, including removeable lever, 6/4mm allen key |
| Rear Hub | MERIDA EXPERT TR, including removeable lever, 6/4mm allen key |
| Tires | Front: Maxxis Assegai, 29×2.5 “, fold, TR EXO+ 3C MaxxGrip, Rear: Maxxis DHR II, 27.5×2.6 “, fold, 3C EXO+ TR |
| Disc Rotors | Shimano RT-MT900 / Shimano RT-EM910, 203 mm |
Electric Components
| Motor | Shimano EP801, 85Nm |
|---|---|
| Battery | Shimano EN806, 630Wh Shimano EN805 504Wh for XS only |
| Display | Shimano SC-EM800 |
| Charger | Shimano EC-E8004, 4A charging current EC-E6002 for Israel, South Africa, Mexico, Argentina |
Accessories
| Lights | LEZYNE E-BIKE POWER STVZO E115, reverse MERIDA Custom Mount / LEZYNE LED FEMTO USB REAR STVZO |
|---|---|
| Fenders | C093-02F + C093-02R |
