Build
| Frame | eSCULTURA LITE, material: aluminium, 700x45C / 700x42C (with fender) / 27,5x47C max. wheelsize, 100×9/135x9mm axle standard, BSA bottom bracket standard, MUK 40 Hanger BB Standard: BSA, 68mm, Threaded Tire Clearance: 45c |
|---|---|
| Fork | MERIDA SCULTURA CF, MDF09, material: carbon, 700x40C w/ fender max wheelsize |
| Bottom Bracket | Shimano BSA |
| Headset | VP MH-P16 |
| Stem | MERIDA EXPERT IR, material: aluminium, 31.8mm diameter, 5 stem angle, 80 mm- XXS/XS, 90 mm-S, 100 mm-SM/ML, 110 mm-L/XL |
| Handlebar | MERIDA EXPERT CW, material: aluminium, 400mm (XS/S), 420mm (M/L), 440 (XL) |
| Saddle | MERIDA COMP SL, V-mount |
| Seatpost | MERIDA EXPERT CC, material: carbon, 30.9mm diameter, 0mm setback Type: Rigid |
| Pedals | VP VPE-891 |
Groupset
| Rear Derailleur | Shimano 105, GS |
|---|---|
| Front Derailleur | Shimano 105 |
| Crank | Shimano 105, 50-34 teeth, 170 mm-XS/S/SM/ML, 175 mm-L/XL |
| Cassette | Shimano 105, 11-32 teeth, 11 speed |
| Chain | KMC e11s |
| Brakes | Shimano 105, 2 piston Type: Hydraulic Disc |
Wheels
| Rims | MERIDA EXPERT SL, 17mm inner width, 22mm height aluminium, Tubeless ready (tubeless tape and valves not included) |
|---|---|
| Spokes | Black stainless |
| Front Hub | VP CLK170F, 100x12mm width front hub, 28 spoke holes, Centerlock |
| Rear Hub | VP CLK170F, 100x12mm width front hub, 28 spoke holes, Centerlock |
| Tires | Front: Maxxis Pursuer, 700x32C, fold, Rear: Maxxis Pursuer, 700x32C, fold |
| Disc Rotors | Shimano RT64 / Shimano RT66, 160 mm |
Electric Components
| Motor | Mahle X35+ Hub Engine, 40Nm |
|---|---|
| Battery | Mahle B1-D, 250Wh |
| Charger | Mahle CHARGER-C, 2A charging current |
Accessories
| Lights | Dlight CG-119PG / Dlight CG-404RG, STZVO, STVZO |
|---|
