Build
| Frame |
eSILEX+ LITE, material: aluminium, 700x45C / 700x42C (with fender) / 27,5x47C max. wheelsize, 100×9/135x9mm axle standard, BSA bottom bracket standard BB Standard:Â BSA, 68mm, Threaded Tire Clearance:Â 45c |
|---|---|
| Fork |
MERIDA SILEX CF2, Tapered, material: carbon, 700x42C max/ 700x35C (with fender) max 50mm for 650B max wheelsize |
| Bottom Bracket |
Shimano BSA |
| Headset |
VP MH-P16 |
| Stem |
MERIDA EXPERT IR, material: aluminium, 31.8mm diameter, 5 stem angle, 80 mm |
| Handlebar |
MERIDA EXPERT GR, material: aluminium, 400mm (XS/S), 420mm (M), 440mm (L/XL) |
| Saddle |
MERIDA COMP CC, V-mount |
| Seatpost |
MERIDA EXPERT CC, material: carbon, 30.9mm diameter, 0mm setback Type:Â Rigid |
| Pedals |
VP VPE-891 |
Groupset
| Rear Derailleur |
Shimano GRX812 |
|---|---|
| Crank |
Shimano GRX600, 40 teeth, 170 mm-XS/S/SM/ML, 175 mm-L/XL |
| Cassette |
Shimano M5100, 11-42 teeth, 11 speed |
| Chain |
KMC e11s |
| Brakes |
Shimano GRX600, 2 piston Type:Â Hydraulic Disc |
Wheels
| Rims |
MERIDA EXPERT CX, 19mm inner width, 24mm height, material: aluminium, Tubeless ready (tubeless tape and valves not included) |
|---|---|
| Spokes |
Black stainless |
| Front Hub |
VP CLK170F, 100x12mm width front hub, 28 spoke holes, Centerlock |
| Rear Hub |
VP CLK170F, 100x12mm width front hub, 28 spoke holes, Centerlock |
| Tires |
Front: Maxxis Rambler, ShieldWall / TLR, 650Bx47, Rear: Maxxis Rambler, ShieldWall / TLR, 650Bx47 |
| Disc Rotors |
Shimano RT64 / Shimano RT66, 160 mm |
Electric Components
| Motor |
Mahle X35+ Hub Engine, 40Nm |
|---|---|
| Battery |
Mahle B1-D, 250Wh |
| Charger |
Mahle CHARGER-C, 2A charging current |
Accessories
| Lights |
Dlight CG-119PG / Dlight CG-404RG, STZVO, STVZO |
|---|
