Build
| Frame | eSILEX+ LITE, material: aluminium, 700x45C / 700x42C (with fender) / 27,5x47C max. wheelsize, 100×9/135x9mm axle standard, BSA bottom bracket standard BB Standard: BSA, 68mm, Threaded Tire Clearance: 45c |
|---|---|
| Fork | MERIDA SILEX CF2, Tapered, material: carbon, 700x42C max/ 700x35C (with fender) max 50mm for 650B max wheelsize |
| Bottom Bracket | Shimano BSA |
| Headset | VP MH-P16 |
| Stem | MERIDA EXPERT IR, material: aluminium, 31.8mm diameter, 5 stem angle, 80 mm |
| Handlebar | MERIDA EXPERT GR, material: aluminium, 400mm (XS/S), 420mm (M), 440mm (L/XL) |
| Saddle | MERIDA COMP CC, V-mount |
| Seatpost | MERIDA EXPERT CC, material: carbon, 30.9mm diameter, 0mm setback Type: Rigid |
| Pedals | VP VPE-891 |
Groupset
| Rear Derailleur | Shimano GRX812 |
|---|---|
| Crank | Shimano GRX600, 40 teeth, 170 mm-XS/S/SM/ML, 175 mm-L/XL |
| Cassette | Shimano M5100, 11-42 teeth, 11 speed |
| Chain | KMC e11s |
| Brakes | Shimano GRX600, 2 piston Type: Hydraulic Disc |
Wheels
| Rims | MERIDA EXPERT CX, 19mm inner width, 24mm height, material: aluminium, Tubeless ready (tubeless tape and valves not included) |
|---|---|
| Spokes | Black stainless |
| Front Hub | VP CLK170F, 100x12mm width front hub, 28 spoke holes, Centerlock |
| Rear Hub | VP CLK170F, 100x12mm width front hub, 28 spoke holes, Centerlock |
| Tires | Front: Maxxis Rambler, ShieldWall / TLR, 650Bx47, Rear: Maxxis Rambler, ShieldWall / TLR, 650Bx47 |
| Disc Rotors | Shimano RT64 / Shimano RT66, 160 mm |
Electric Components
| Motor | Mahle X35+ Hub Engine, 40Nm |
|---|---|
| Battery | Mahle B1-D, 250Wh |
| Charger | Mahle CHARGER-C, 2A charging current |
Accessories
| Lights | Dlight CG-119PG / Dlight CG-404RG, STZVO, STVZO |
|---|
