Build
| Frame |
eSPRESSO LITE, material: aluminium, 700C wheelsize, 142x12mm axle standard, MUK 37 Hanger BB Standard:Â BSA, Threaded |
|---|---|
| Fork |
SR Suntour NEX-PM-DS, Coil, 63mm suspension travel, 700x48C max wheelsize Travel:Â 63mm Spring Type:Â Coil |
| Bottom Bracket |
BSA, threaded |
| Headset |
MERIDA 2346 |
| Stem |
MERIDA EXPERT CC, material: aluminium, 31.8mm diameter, 17 stem angle, 80 mm-XS/S, 90 mm-M, 100 mm-L, 110 mm-XL |
| Handlebar |
MERIDA EXPERT TK, material: aluminium, 660mm width, 15mm rise |
| Saddle |
MERIDA EXPERT TK, V-mount |
| Seatpost |
MERIDA EXPERT, material: aluminium, 30.9mm diameter, 15mm setback Type:Â Rigid |
| Pedals |
VP VPE-891 |
Groupset
| Rear Derailleur |
Shimano Altus M2000, SGS |
|---|---|
| Crank |
Shimano CRE50, 38 teeth |
| Shifters |
Shimano Altus |
| Cassette |
Shimano HG400, 11-36 teeth, 9 speed |
| Chain |
KMC e9S |
| Brakes |
Shimano MT200, 2 piston Type:Â Hydraulic Disc |
Wheels
| Rims |
MERIDA COMP TK, 20mm inner width, material: aluminium |
|---|---|
| Front Hub |
Shimano TX505 / Shimano MT400, 100x9mm width front hub, 32 spoke holes, Centerlock, 142x12mm width rear hub, 36 spoke holes, Centerlock |
| Rear Hub |
Shimano TX505 / Shimano MT400, 100x9mm width front hub, 32 spoke holes, Centerlock, 142x12mm width rear hub, 36 spoke holes, Centerlock |
| Tires |
Front: Continental Ride Tour, 622×42″, reflective stripe, Rear: Continental Ride Tour, 622×42″, reflective stripe |
| Disc Rotors |
Shimano RT10, 180 mm, 160 mm |
Electric Components
| Motor |
Shimano E5000, 40Nm |
|---|---|
| Battery |
Shimano E8014, 418Wh |
| Display |
Shimano SC-E5000A |
| Charger |
Shimano EC-E6002, 2A charging current |
Accessories
| Lights |
Herrmans H-Black MR4 E / Herrmans H-Cargo, STVZO, STVZO, integrated in MERIDA MIK carrier |
|---|---|
| Fenders |
Sunnywheel SW-FA 513 |
| Racks |
MERIDA MIK, Spring clip, Herrmans rear light |
| Lock |
Abus 5650 LH-3 lock |
| Stand |
Massload CL-KA98 |
