Build
| Frame | eSPRESSO LITE, material: aluminium, 700C wheelsize, 142x12mm axle standard, MUK 37 Hanger BB Standard: BSA, Threaded |
|---|---|
| Fork | SR Suntour NEX-PM-DS, Coil, 63mm suspension travel, 700x48C max wheelsize Travel: 63mm Spring Type: Coil |
| Bottom Bracket | BSA, threaded |
| Headset | MERIDA 2346 |
| Stem | MERIDA EXPERT CC, material: aluminium, 31.8mm diameter, 17 stem angle, 80 mm-XS/S, 90 mm-M, 100 mm-L, 110 mm-XL |
| Handlebar | MERIDA EXPERT TK, material: aluminium, 660mm width, 15mm rise |
| Saddle | MERIDA EXPERT TK, V-mount |
| Seatpost | MERIDA EXPERT, material: aluminium, 30.9mm diameter, 15mm setback Type: Rigid |
| Pedals | VP VPE-891 |
Groupset
| Rear Derailleur | Shimano Altus M2000, SGS |
|---|---|
| Crank | Shimano CRE50, 38 teeth |
| Shifters | Shimano Altus |
| Cassette | Shimano HG400, 11-36 teeth, 9 speed |
| Chain | KMC e9S |
| Brakes | Shimano MT200, 2 piston Type: Hydraulic Disc |
Wheels
| Rims | MERIDA COMP TK, 20mm inner width, material: aluminium |
|---|---|
| Front Hub | Shimano TX505 / Shimano MT400, 100x9mm width front hub, 32 spoke holes, Centerlock, 142x12mm width rear hub, 36 spoke holes, Centerlock |
| Rear Hub | Shimano TX505 / Shimano MT400, 100x9mm width front hub, 32 spoke holes, Centerlock, 142x12mm width rear hub, 36 spoke holes, Centerlock |
| Tires | Front: Continental Ride Tour, 622×42″, reflective stripe, Rear: Continental Ride Tour, 622×42″, reflective stripe |
| Disc Rotors | Shimano RT10, 180 mm, 160 mm |
Electric Components
| Motor | Shimano E5000, 40Nm |
|---|---|
| Battery | Shimano E8014, 418Wh |
| Display | Shimano SC-E5000A |
| Charger | Shimano EC-E6002, 2A charging current |
Accessories
| Lights | Herrmans H-Black MR4 E / Herrmans H-Cargo, STVZO, STVZO, integrated in MERIDA MIK carrier |
|---|---|
| Fenders | Sunnywheel SW-FA 513 |
| Racks | MERIDA MIK, Spring clip, Herrmans rear light |
| Lock | Abus 5650 LH-3 lock |
| Stand | Massload CL-KA98 |
