Build
| Frame | eSPRESSO LITE II, material: aluminium, 700x50C (with fender) max. wheelsize, 142x12mm axle standard, MUK 37 Hanger BB Standard: BSA, Threaded Tire Clearance: 50c |
|---|---|
| Fork | SR Suntour NEX E25, Coil, 63mm suspension travel, 700x52C max wheelsize Travel: 63mm Spring Type: Coil |
| Bottom Bracket | BSA, threaded |
| Headset | MERIDA 2346 |
| Stem | MERIDA EXPERT CT, material: aluminium, 31.8mm diameter, adjustable, 90 mm-XS/S/M, 110 mm-L/XL |
| Handlebar | MERIDA EXPERT TK, material: aluminium, 660mm width, 15mm rise |
| Saddle | MERIDA EXPERT TK, V-mount |
| Seatpost | MERIDA EXPERT CC, material: aluminium, 34.9mm diameter, 0mm setback Type: Rigid |
| Pedals | VP VPE-891 |
Groupset
| Rear Derailleur | Shimano ALIVIO M3100, SGS |
|---|---|
| Crank | Shimano CRE61, 38 teeth |
| Shifters | Shimano Alivio |
| Cassette | Shimano HG200, 11-36 teeth, 9 speed |
| Chain | KMC e9S |
| Brakes | Shimano MT200, 2 piston Type: Hydraulic Disc |
Wheels
| Rims | MERIDA COMP TK, 20mm inner width, material: aluminium |
|---|---|
| Front Hub | Shimano TX505 / Shimano MT400, 100x9mm width front hub, 32 spoke holes, Centerlock, 142x12mm width rear hub, 36 spoke holes, Centerlock |
| Rear Hub | Shimano TX505 / Shimano MT400, 100x9mm width front hub, 32 spoke holes, Centerlock, 142x12mm width rear hub, 36 spoke holes, Centerlock |
| Tires | Front: Continental Ride Cruiser, 622-50, wire, reflecting line, Rear: Continental Ride Cruiser, 622-50, wire, reflecting line |
| Disc Rotors | Shimano RT10, 180 mm |
Electric Components
| Motor | Shimano E6100, 60Nm |
|---|---|
| Battery | Shimano E8035, 504Wh |
| Display | Shimano SC-E5000A |
| Charger | Shimano EC-E6002, 2A charging current |
Accessories
| Lights | Herrmans H-Black MR4 E / Spanninga Commuter Glow XE, STVZO, STVZO, integrated in MERIDA MIK HD carrier |
|---|---|
| Fenders | Sunnywheel SW-FA311-60E1 (MSB) |
| Racks | MERIDA MIK HD, Spring clip, Spanninga rear light |
| Lock | Abus 5650 LH-3 lock |
| Stand | Massload CL-KA98 |
