Build
| Frame |
eSPRESSO LITE IV, material: aluminium, 700x50C (with fender) max. wheelsize, 142×12 mm axle standard, intube BB Standard:Â BSA, Threaded Tire Clearance:Â 50c |
|---|---|
| Fork |
SR Suntour NEX E25, Coil, 63 mm suspension travel, 700x52C max. wheelsize Travel:Â 63mm Spring Type:Â Coil |
| Bottom Bracket |
BSA, threaded |
| Headset |
MERIDA 8156 |
| Stem |
MERIDA EXPERT CT, material: aluminium, 31.8 mm diameter, adjustable, 90 mm-XS/S/M, 110 mm-L/XL |
| Handlebar |
MERIDA EXPERT, material: aluminium, 660 mm width, 15 mm rise |
| Saddle |
MERIDA EXPERT TK II, V-mount |
| Seatpost |
MERIDA EXPERT CC, material: aluminium, 34.9 mm diameter, 0 mm setback Type:Â Rigid |
| Pedals |
VP VPE-891 |
Groupset
| Rear Derailleur |
Shimano CUES U6000, GS |
|---|---|
| Crank |
Samox NWP203, 38 teeth |
| Shifters |
Shimano CUES U6000 |
| Cassette |
Shimano LG300, 11-48 teeth, 10 speed |
| Chain |
Shimano LG500 |
| Chain Guide |
Sunnywheel SW-CG-173A |
| Brakes |
Shimano MT-200, 2 piston Type:Â Hydraulic Disc |
Wheels
| Rims |
MERIDA COMP TK, 20 mm inner width, material: aluminium |
|---|---|
| Spokes |
Black stainless |
| Front Hub |
Shimano QC300 / Shimano TC500-HM, 100×9 mm width front hub, 32 spoke holes, Centerlock, 142×12 mm width rear hub, 32 spoke holes, Centerlock |
| Rear Hub |
Shimano QC300 / Shimano TC500-HM, 100×9 mm width front hub, 32 spoke holes, Centerlock, 142×12 mm width rear hub, 32 spoke holes, Centerlock |
| Tires |
Front: Continental Ride Cruiser, 622-50, wire, reflecting line, Rear: Continental Ride Cruiser, 622-50, wire, reflecting line |
| Disc Rotors |
Shimano RT10, 180 mm |
Electric Components
| Motor |
Shimano EP6, 85Nm |
|---|---|
| Battery |
Trendpower Internal Battery 750Wh |
| Display |
Shimano SC-EN610 |
| Charger |
Simplo EU Charger, 4A |
Accessories
| Lights |
Herrmans H-Black MR4 E / Spanninga Co mmuter Glow XE integrated in MERIDA MIK HD carrier |
|---|---|
| Fenders |
Sunnywheel SW-FA311-60E1 (MSB) |
| Racks |
MERIDA MIK HD Carrier with Spring clip |
| Lock |
Abus 4750 L |
| Stand |
Massload CL-KA98 |
