Build
Frame |
eSPRESSO CC LITE III, material: aluminium, 27,5×2,25″ max. wheelsize, 135×9 mm axle standard, internal BB Standard:Â BSA, Threaded |
---|---|
Fork |
SR Suntour NVX30 DS, Coil, 80 mm suspension travel, 27,5×2,4″ max. wheelsize Travel:Â 80mm Spring Type:Â Coil |
Bottom Bracket |
BSA, threaded |
Headset |
MERIDA 8254 |
Stem |
MERIDA EXPERT CT, material: aluminium, 31.8 mm diameter, adjustable, 90 mm- XS/S/M/L/XL |
Handlebar |
MERIDA EXPERT, material: aluminium, 660 mm width, 15 mm rise |
Saddle |
MERIDA EXPERT TK II, V-mount |
Seatpost |
JD SP79, 30.9 mm diameter, 15 mm setback, 40 mm seatpost suspension travel Type:Â Suspension |
Pedals |
VP VPE-891 |
Groupset
Rear Derailleur |
Shimano CUES U4000 |
---|---|
Crank |
Samox NWP203, 38 teeth |
Shifters |
Shimano CUES U4000 |
Cassette |
Shimano LG300, 11-46 teeth, 9 speed |
Chain |
Shimano LG500 |
Chain Guide |
Sunnywheel SW-CG-173A |
Brakes |
Shimano MT-200, 2 piston Type:Â Hydraulic Disc |
Wheels
Rims |
MERIDA COMP TK, 20 mm inner width, material: aluminium |
---|---|
Spokes |
Black stainless |
Front Hub |
Shimano QC300, 100×9 mm width front hub, 32 spoke holes, Centerlock, 135×9 mm width rear hub, 32 spoke holes, Centerlock |
Rear Hub |
Shimano QC300, 100×9 mm width front hub, 32 spoke holes, Centerlock, 135×9 mm width rear hub, 32 spoke holes, Centerlock |
Tires |
Front: Maxxis Crossmark II, 27.5×2.25″, wire, reflecting line, Rear: Maxxis Crossmark II, 27.5×2.25″, wire, reflecting line |
Disc Rotors |
Shimano RT10, 180 mm |
Electric Components
Motor |
Shimano EP6, 85Nm |
---|---|
Battery |
Shimano EN805-L 504Wh |
Display |
Shimano SC-EN500 |
Charger |
Shimano EC-E6002, 2A charging current |
Accessories
Lights |
Herrmans H-Black MR4 E / Spanninga Co mmuter Glow XE integrated in MERIDA MIK HD carrier |
---|---|
Fenders |
Sunnywheel SW-FA-311-65(MSB) |
Racks |
MERIDA MIK HD Carrier with Spring clip |
Lock |
Abus 4650 XL |
Stand |
Atranvelo ED-100-PC |
