Build
| Frame |
eSPRESSO LITE 650, material: aluminium, 27,5×2,25 max. wheelsize, 135x9mm axle standard, external, max. 504 Wh BB Standard:Â BSA, Threaded |
|---|---|
| Fork |
Suntour NVX30 DS, Coil, 80mm suspension travel, 27,5×2,4″ max wheelsize Travel:Â 80mm Spring Type:Â Coil |
| Bottom Bracket |
BSA, threaded |
| Headset |
MERIDA 2346 Neck |
| Handlebar |
MERIDA EXPERT, material: aluminium, 660mm width, 15mm rise |
| Saddle |
MERIDA EXPERT TK, V-mount |
| Seatpost |
JD-SP79, 30.9mm diameter, 15mm setback, 40mm seatpost suspension travel Type:Â Suspension |
| Pedals |
VP VPE-891 |
Groupset
| Rear Derailleur |
Shimano Deore M3100, SGS |
|---|---|
| Crank |
Shimano FC-EN600, 165mm |
| Shifters |
Shimano Alivio M3100 |
| Cassette |
Shimano HG200, 11-36 teeth, 9 speed |
| Chain |
KMC e9S |
| Chain Guide |
Sunnywheel SW-CG-173A |
| Brakes |
Shimano MT-200, 2 piston Type:Â Hydraulic Disc |
Wheels
| Rims |
MERIDA COMP TK, 20mm inner width, material: aluminium |
|---|---|
| Spokes |
Black stainless |
| Front Hub |
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock |
| Rear Hub |
Shimano TX505, 135x9mm width rear hub, 36 spoke holes, Centerlock |
| Tires |
Maxxis Crossmark II, 27.5×2.25″, wire, reflecting line |
Electric Components
| Motor |
Shimano EP6, 85Nm |
|---|---|
| Battery |
Shimano EN605, 504Wh |
| Display |
Shimano SC-EN500 |
Accessories
| Fenders |
Sunnywheel SW-FA-311-65(MSB) |
|---|---|
| Racks |
MERIDA MIK HD Carrier with Spring clip & Spanninga rear light |
| Lock |
Abus 4750 L |
| Stand |
Massload CL-KA100K-Mount |
