Build
| Frame | eSPRESSO CC LITE III, material: aluminium, 27,5×2,25″ max. wheelsize, 135x9mm axle standard, internal BB Standard: BSA, Threaded |
|---|---|
| Fork | SR Suntour NVX30 DS, Coil, 80mm suspension travel, 27,5×2,4″ max wheelsize Travel: 80mm Spring Type: Coil |
| Bottom Bracket | BSA, threaded |
| Headset | MERIDA-8254 |
| Handlebar | MERIDA EXPERT, material: aluminium, 660mm width, 15mm rise |
| Saddle | MERIDA EXPERT TK II |
| Seatpost | MERIDA EXPERT TK, 30.9mm diameter, 15mm setback, 40mm seatpost suspension travel Type: Suspension |
| Pedals | VP VPE-891 |
Groupset
| Rear Derailleur | Shimano CUES U6000, GS |
|---|---|
| Crank | Samox NWP203, 38 teeth |
| Shifters | Shimano CUES U6000 |
| Cassette | Shimano LG300, 11-48 teeth, 10 speed |
| Chain | Shimano LG500 |
| Chain Guide | Sunnywheel SW-CG-173A |
| Brakes | Shimano MT200, 2 piston Type: Hydraulic Disc |
Wheels
| Rims | MERIDA COMP TK, 20mm inner width, material: aluminium |
|---|---|
| Spokes | Black stainless |
| Front Hub | Shimano QC300, 100x9mm width front hub, 32 spoke holes, Centerlock |
| Rear Hub | Shimano QC300, 135x9mm width rear hub, 32 spoke holes, Centerlock |
| Tires | Maxxis Crossmark II, 27.5×2.25″, wire, reflecting line |
| Disc Rotors | Shimano RT10 / Shimano RTEM300, 180 mm |
Electric Components
| Motor | Shimano EP6, 85Nm |
|---|---|
| Battery | Shimano EN806 630 Wh, removeable, No Range Extender compatibility |
| Display | Shimano SC-EN500 |
Accessories
| Fenders | Sunnywheel SW-FA-311-65(MSB) |
|---|---|
| Racks | MERIDA MIK HD Carrier with Spring clip & Spanninga rear light |
| Lock | Abus 4650 XL |
| Stand | Atranvelo ED-100-PC |
