Build
Frame |
eSPRESSO CITY LITE, material: aluminium, 700x 42C (with fender) wheelsize, 142x12mm axle standard, external, max. 504 Wh BB Standard:Â BSA, Threaded Tire Clearance:Â 42c |
---|---|
Fork |
SR Suntour NEX-PM-DS, Coil, 63mm suspension travel, 700x48C max wheelsize Travel:Â 63mm Spring Type:Â Coil |
Bottom Bracket |
BSA, threaded |
Headset |
MERIDA 2346 |
Handlebar |
MERIDA EXPERT TK, material: aluminium, 640mm width, 35mm rise |
Saddle |
MERIDA EXPERT TK, V-mount |
Seatpost |
MERIDA EXPERT TK, 30.9mm diameter, 15mm setback, 40mm seatpost suspension travel Type:Â Suspension |
Groupset
Rear Derailleur |
Shimano Altus M2000, SGS |
---|---|
Crank |
Shimano CRE50, 38 teeth |
Shifters |
Shimano Altus |
Cassette |
Shimano HG400, 11-36 teeth, 9 speed |
Chain |
KMC e9S |
Brakes |
Shimano MT200, 2 piston Type:Â Hydraulic Disc |
Wheels
Rims |
MERIDA COMP TK, 20mm inner width, material: aluminium |
---|---|
Spokes |
Black stainless |
Front Hub |
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock |
Rear Hub |
Shimano MT400, 142x12mm width rear hub, 36 spoke holes, Centerlock |
Tires |
Continental Contact Plus, 622-47, wire, reflecting line |
Disc Rotors |
Shimano RT10, 180 mm, 160 mm |
Electric Components
Motor |
Shimano E5000, 40Nm |
---|---|
Battery |
Shimano E8010, 504Wh |
Display |
Shimano SC-E5000A |
Accessories
Fenders |
Sunnywheel SW-FA311-60E1 (MSB) |
---|---|
Racks |
MERIDA MIK, Spring clip, Herrmans rear light |
Stand |
Massload CL-KA98 |
