Build
| Frame |
eSPRESSO CITY LITE II, material: aluminium, 700x50C (with fender) max. wheelsize, 135x9mm axle standard, MUK 5 Hanger BB Standard:Â BSA, Threaded Tire Clearance:Â 50c |
|---|---|
| Fork |
SR Suntour NEX E25, Coil, 63mm suspension travel, 700x52C max wheelsize Travel:Â 63mm Spring Type:Â Coil |
| Bottom Bracket |
BSA, threaded |
| Headset |
MERIDA 8152 |
| Stem |
MERIDA EXPERT TK, material: aluminium, 31.8mm diameter, adjustable, 65 mm-XS/S/M, 90 mm-L/XL |
| Handlebar |
MERIDA EXPERT TK, material: aluminium, 640mm width, 35mm rise |
| Saddle |
MERIDA EXPERT TK, V-mount |
| Seatpost |
MERIDA EXPERT TK, 30.9mm diameter, 15mm setback, 40mm seatpost suspension travel Type:Â Suspension |
| Pedals |
VP VPE-891 |
Groupset
| Rear Derailleur |
Shimano ALIVIO M3100, SGS |
|---|---|
| Crank |
Shimano CRE61, 38 teeth |
| Shifters |
Shimano Alivio |
| Cassette |
Shimano HG200, 11-36 teeth, 9 speed |
| Chain |
KMC e9S |
| Chain Guide |
Sunnywheel SW-CG-173A |
| Brakes |
Shimano MT200, 2 piston Type:Â Hydraulic Disc |
Wheels
| Rims |
MERIDA COMP TK, 20mm inner width, material: aluminium |
|---|---|
| Spokes |
Black stainless |
| Front Hub |
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 36 spoke holes, Centerlock |
| Rear Hub |
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 36 spoke holes, Centerlock |
| Tires |
Front: Continental Ride Cruiser, 622-50, wire, reflecting line, Rear: Continental Ride Cruiser, 622-50, wire, reflecting line |
| Disc Rotors |
Shimano RT10 / Shimano RTEM300, 180 mm |
Electric Components
| Motor |
Shimano E6100, 60Nm |
|---|---|
| Battery |
Shimano E8035-L, 504Wh |
| Display |
Shimano SC-E5000A |
| Charger |
Shimano EC-E6002, 2A charging current |
Accessories
| Lights |
Herrmans H-Black MR4 E / Spanninga Commuter Glow XE, STVZO, STVZO, integrated in MERIDA MIK HD carrier |
|---|---|
| Fenders |
Sunnywheel SW-FA311-60E1 (MSB) |
| Racks |
MERIDA MIK HD, Spring clip, Spanninga rear light |
| Lock |
Abus 4650 XL |
| Stand |
Atranvelo 1219-PC-7 |
