Build
| Frame | eSPRESSO CITY LITE II HG, material: aluminium, 700x50C max. wheelsize, 135x9mm axle standard, hub-gear dropout BB Standard: BSA, Threaded Tire Clearance: 50c |
|---|---|
| Fork | SR Suntour NEX E25, Coil, 63mm suspension travel, 700x52C max wheelsize Travel: 63mm Spring Type: Coil |
| Bottom Bracket | BSA, threaded |
| Headset | MERIDA 8152 |
| Stem | MERIDA EXPERT TK, material: aluminium, 31.8mm diameter, adjustable, 65 mm-XS/S/M, 90 mm-L/XL |
| Handlebar | MERIDA EXPERT TK, material: aluminium, 640mm width, 35mm rise |
| Saddle | MERIDA EXPERT TK, V-mount |
| Seatpost | MERIDA EXPERT TK, 30.9mm diameter, 15mm setback, 40mm seatpost suspension travel Type: Suspension |
| Pedals | VP VPE-891 |
Groupset
| Crank | Shimano CRE61, 38 teeth |
|---|---|
| Shifters | Shimano SW-E6010-R |
| Cassette | Shimano CS-C7000, 30 teeth |
| Chain | KMC Z1eHX EPT |
| Brakes | Shimano MT402-3A, 2 piston Type: Hydraulic Disc |
Wheels
| Rims | MERIDA COMP TK, 20mm inner width, material: aluminium |
|---|---|
| Front Hub | Shimano M4050 / Shimano Nexus Inter-5E, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 36 spoke holes, Centerlock |
| Rear Hub | Shimano M4050 / Shimano Nexus Inter-5E, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 36 spoke holes, Centerlock |
| Tires | Front: Continental Contact Cruiser, 622-50, wire, reflecting line, Rear: Continental Contact Cruiser, 622-50, wire, reflecting line |
| Disc Rotors | Shimano RT30 / Shimano RTEM300, 180 mm |
Electric Components
| Motor | Shimano E6100, 60Nm |
|---|---|
| Battery | Shimano E8036, 630Wh |
| Display | Shimano SC-E6100 |
| Charger | Shimano EC-E6002, 2A charging current |
Accessories
| Lights | Herrmans H-Black MR4 E / Spanninga Commuter Glow XE, STVZO, STVZO, integrated in MERIDA MIK HD carrier |
|---|---|
| Fenders | Sunnywheel SW-FA311-60E1 (MSB) |
| Racks | MERIDA MIK HD, Spring clip, Spanninga rear light |
| Lock | Abus 4650 XL |
| Stand | Atranvelo 1219-PC-7 |
