Build
| Frame |
eSPRESSO L LITE II, material: aluminium, 700x50C (with fender) max. wheelsize, 142x12mm axle standard, intube, max. 504 Wh BB Standard:Â BSA, Threaded Tire Clearance:Â 50c |
|---|---|
| Fork |
Suntour NEX E25, Coil, 63mm suspension travel, 700x52C max wheelsize Travel:Â 63mm Spring Type:Â Coil |
| Bottom Bracket |
BSA, threaded |
| Headset |
MERIDA 2346 Neck |
| Handlebar |
MERIDA EXPERT TK, material: aluminium, 660mm width, 15mm rise |
| Saddle |
MERIDA EXPERT TK, V-mount |
| Seatpost |
MERIDA EXPERT CC, material: aluminium, 34.9mm diameter, 0mm setback Type:Â Rigid |
Groupset
| Rear Derailleur |
Shimano ALIVIO M3100, SGS |
|---|---|
| Crank |
Shimano CRE61, 38 teeth, Shimano FC-E6100 |
| Shifters |
Shimano Alivio M3100 |
| Cassette |
Shimano HG200, 11-36 teeth, 9 speed |
| Chain |
KMC e9S |
| Brakes |
Shimano MT200, 2 piston Type:Â Hydraulic Disc |
Wheels
| Rims |
MERIDA COMP TK, 20mm inner width, material: aluminium |
|---|---|
| Spokes |
Black stainless |
| Front Hub |
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock |
| Rear Hub |
Shimano MT400, 142x12mm width rear hub, 36 spoke holes, Centerlock |
| Tires |
Continental Ride Cruiser, 622-50, wire, reflecting line |
| Disc Rotors |
Shimano RT10, 180 mm |
Electric Components
| Motor |
Shimano E6100, 60Nm |
|---|---|
| Battery |
Shimano E8035, 504Wh |
| Display |
Shimano SC-E5000A |
Accessories
| Fenders |
Sunnywheel SW-FA311-60E1 (MSB) |
|---|---|
| Racks |
MERIDA MIK HD Carrier with Spring clip & Spanninga rear light |
| Stand |
Massload CL-KA98 |
