Build
| Frame | eSPRESSO URBAN LITE BB Standard: BSA, Threaded Tire Clearance: 50c |
|---|---|
| Fork | SR Suntour NEX E25, Coil, 63mm suspension travel, 700x52C max wheelsize Travel: 63mm Spring Type: Coil |
| Bottom Bracket | BSA, threaded |
| Headset | MERIDA 8254 |
| Handlebar | MERIDA EXPERT TK, material: aluminium, 640mm width, 35mm rise |
| Saddle | MERIDA EXPERT TK, V-mount |
| Seatpost | MERIDA EXPERT, material: aluminium, 30.9mm diameter, 0mm setback Type: Rigid |
| Pedals | VP VPE-891 |
Groupset
| Rear Derailleur | Shimano Alivio, SGS |
|---|---|
| Crank | MERIDA COMP TK, 42 teeth, XS-165mm, S/M/L-170mm, XL-175mm |
| Shifters | Shimano Alivio |
| Cassette | Shimano CS-HG201, 11-36 teeth, 9 speed |
| Chain | KMC e9S |
| Chain Guide | Sunnywheel SW-CG-173B, 42/44T |
| Brakes | Shimano MT200, 2 piston Type: Hydraulic Disc |
| Brake Levers | attached to brake |
Wheels
| Rims | MERIDA COMP TK, 20mm inner width, material: aluminium |
|---|---|
| Spokes | Black stainless |
| Front Hub | Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock |
| Rear Hub | Shimano QC300, 100×9 mm width front hub, 32 spoke holes, Centerlock |
| Tires | Continental Contact Urban, 622-50, wire, reflecting line |
| Disc Rotors | Shimano SM-RT10 / Shimano SM-RT26, 180mm |
Electric Components
| Motor | Mahle X35+ Hub Engine, 40Nm |
|---|---|
| Battery | Mahle B1-D, 250Wh |
Accessories
| Fenders | Sunnywheel SW-FA311-60 (MSB) |
|---|---|
| Racks | MERIDA MIK HD, Spring clip, Spanninga rear light |
| Lock | Abus 4650L |
| Stand | Atranvelo 1219-PC-7 |
