2023 Merida ONE-FORTY 700 A 27.5″ aluminum frame full suspension trail bike with upper mid-range components.
Build
| Frame | ONE-FORTY LITE III, 143mm suspension travel 29″, material: aluminium, 29×2.5″ max. wheelsize, 148x12mm axle standard, BSA bottom bracket standard, SRAM-UDH Hanger BB Standard: BSA, 68mm, Threaded |
|---|---|
| Fork | Marzocchi Z1, Air, 150mm suspension travel, Tapered, 44mm fork offset, 29×2.6″ max. wheelsize |
| Rear Shock | Rock Shox Deluxe Select+, lockout |
| Bottom Bracket | Race Face BSA 68/73 – 24mm |
| Headset | MERIDA 8158 |
| Stem | MERIDA EXPERT eTRII, material: aluminium, 35mm diameter, 0° stem angle, 50 mm |
| Handlebar | MERIDA TEAM TR, material: aluminium, 780mm width, XS/S 18mm rise, M/L/XL 30mm rise |
| Saddle | MERIDA EXPERT SL, V-mount, incl. MERIDA minitool |
| Seatpost | MERIDA TEAM TR, 34.9mm diameter, 10mm setback, 30-230mm travel seatpost |
Groupset
| Rear Derailleur | Shimano SLX M7100 Shadow+, SGS |
|---|---|
| Crank | Race Face Aeffect, 32 teeth, 170 mm-S, 175 mm-M up |
| Shifters | Shimano SL -MT500-IL / Shimano XT, Multi Release |
| Cassette | Shimano Deore M6100, 10-51 teeth, 12 speed |
| Chain | KMC X12 |
| Brakes | Shimano SLX M7120, 4 piston |
