Build
| Frame |
Chaser 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 140mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers, shock mudguard |
|---|---|
| Fork |
RockShox 35 Silver TK 29, 150mm, TurnKey, Solo Air, tapered steerer tube, Boost 15x110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload Travel:Â 150mm Spring Type:Â Air |
| Shock |
RockShox Deluxe Select R DebonAir, 205x60mm. Settings: Low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings Travel:Â 140mm |
| Headset |
Onoff Saturn tapered for 1-1/8 to 1-1/2 head tube, ACB sealed bearings, top 41×30.2x7x45x45, bottom 51.9x40x8x45x45 |
| Stem |
MDK Urban 35mm 0, 6061 forged alloy, 31.8mm barbore |
| Handlebar |
Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9 backsweep, 5 upsweep, 31.8mm barbore |
| Saddle |
MDK urban |
| Seatpost |
Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 405×95-125mm, M size: 458×120-150mm, L size: 498×140-170mm, XL size: 558×170-200mm Type:Â Dropper |
| Pedals |
Urban pedal resin black |
| Grips |
Onoff Twin, 1lock-on, 135mm |
Groupset
| Rear Derailleur |
SRAM GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1 |
|---|---|
| Crank |
Race Face Aeffect ebike, 165mm, Rings: SRAM X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD |
| Shifters |
SRAM Trigger SX Eagle, 12s, X-Actuation 1:1, single click |
| Chain |
SRAM SX Eagle, 12s, Powerlock |
| Brakes |
Front: SRAM DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads, Rear: SRAM DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads Type:Â Hydraulic Disc |
| Brake Levers |
SRAM DB8, tool reach adjust, lever pivot bushings |
Wheels
| Rims |
MDK-HP1 29, 30mm internal width, tubeless ready, 32 spokes |
|---|---|
| Spokes |
CN round stainless steel |
| Front Hub |
Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts |
| Rear Hub |
Formula EHL148 Boost 12x148mm, sealed bearings, IS 6 bolts, HG freehub |
| Tires |
Front: Maxxis Ikon 29×2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead, Rear: Maxxis Ikon 29×2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead |
Electric Components
| Motor |
Bosch Performance Line CX Cruise (25Km/h) GEN4 SMART SYSTEM |
|---|---|
| Battery |
Bosch Powertube 750Wh |
| Display |
Bosch Kiox 500 / Bosch Mini Remote / Bosch System Controller |
