Build
Frame |
Dusty Stealth Air Carbon, pressfit 386 EVO bottom bracket, tapered head tube, HHG internal cable routing, integrated internal non-removable battery, 12x142mm rear axle, 1X or 2X drivetrain design, Flatmount brake compatible, integrated dropout speed sensor. BB Standard:Â 386EVO, 86mm, Press Fit |
---|---|
Fork |
Steatlh Air Carbon tapered steerer tube, HHG, fllat mount integrated fork |
Bottom Bracket |
Mahle DUB pressfit, sealed bearings, w/ torque sensor |
Headset |
OnOff gravel tapered for 1-1/8 to 1-1/2 head tube, ACB sealed bearings, top 41×30.2x7x45x45, bottom 51.9x40x8x45x45 |
Stem |
OnOff gravel 6061 T6 Alloy, 31.8mm barbore, rise: +/-7, length: sizes S/M: 70mm, size L: 80mm, XL: 90mm |
Handlebar |
MDK Urban 1.0 double butted 6061 alloy, rise: 0mm, width: 640mm, 9 backsweep, 0 upsweep, 31.8mm barbore |
Saddle |
Selle Royal Prestige 139mm |
Seatpost |
Seatpost with integrated Supernova led rear light, diameter 27.2mm, length 400mm Type:Â Rigid |
Grips |
Lizard Skins DSP 30.3 |
Groupset
Rear Derailleur |
SRAM Apex XPLR 12s |
---|---|
Crank |
SRAM Apex 1 Wide, S: 170mm, M: 172,5mm, L: 172,5mm, XL: 175mm., Rings: SRAM X-Sync Eagle 40T direct mount, alloy, narrow-wide, |
Shifters |
SRAM Trigger GX Eagle, 12s, X-Actuation 1:1 |
Chain |
SRAM Apex, 12s, Powerlock |
Brakes |
Front: SRAM Level Silver 2P Stealth, 2 piece flatmount caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad, Rear: SRAM Level Silver 2P Stealth, 2 piece flatmount caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad Type:Â Hydraulic Disc |
Brake Levers |
SRAM Level Silver, tools-free reach adjust, lever pivot bearings |
Wheels
Rims |
MDK-XG1, 23mm internal width, tubeless ready, 28 spokes |
---|---|
Spokes |
CN round stainless steel |
Front Hub |
Novatec D041, Boost 12x100mm, sealed bearings, IS 6 bolts |
Rear Hub |
Mahle X20 Drive Unit, HG freehub |
Tires |
Front: Maxxis Re-fuse 700×40, tubeless ready, dual compound, MaxxShield EXO protection, 60 TPI, folding bead, light tan wall, Rear: Maxxis Re-fuse 700×40, tubeless ready, dual compound, MaxxShield EXO protection, 60 TPI, folding bead, light tan wall |
Electric Components
Motor |
Mahle X20 Drive Unit |
---|---|
Battery |
Mahle X20 IX350Wh |
Display |
Pulsar One Wireless/ DUO remote |
