Build
| Frame | F-Play 26 6061 Alloy Stealth evo, hydroformed tubing, Zero Suspension System, 130mm travel, one piece bolt-on upper link, integrated internal non-removable battery, Tapered head tube, HHG internal cable routing, BSA bottom bracket, QR 9mm rear axle, 1x drivetrain compatible BB Standard: BSA, 73mm, Threaded |
|---|---|
| Fork | X-Fusion Velvet RL 26, 140mm, air spring, tapered steerer tube, 15x100mm axle, 32mm aluminum stanchions, 41mm offset. Settings: lockout, rebound, air preload Travel: 140mm Spring Type: Air |
| Shock | X-Fusion 02PRO R, 165x45mm. Settings: low-speed rebound, air preload. Trunnion top, 50x8mm bottom bushings Travel: 130mm |
| Bottom Bracket | SRAM DUB BSA, sealed bearings, 73mm |
| Headset | Acros AZX-239 R1 Block Lock 135, ZS44/28.6 top, ZS56/40 bottom |
| Stem | Onoff Sulfur FG 30mm 0, 6061 forged alloy, 31.8mm barbore |
| Handlebar | MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9 backsweep, 5 upsweep, 31.8mm barbore |
| Saddle | SDG Fly JR |
| Seatpost | Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever, 405×95-125mm Type: Dropper |
| Pedals | SDG Slater JR |
| Grips | Onoff Twin, 1lock-on |
Groupset
| Rear Derailleur | SRAM SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1 |
|---|---|
| Crank | SRAM SX Eagle, DUB axle, Direct mount chain ring, 155mm, Rings: 30T, steel, X-Sync |
| Shifters | SRAM Trigger SX Eagle, 12s, X-Actuation 1:1 |
| Chain | SRAM SX Eagle, 12s, Powerlock |
| Brakes | Front: SRAM G2 R, 4 pistonr, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad, Rear: SRAM G2 R, 2 piston, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad Type: Hydraulic Disc |
| Brake Levers | SRAM G2 R, tool-free reach adjust, lever pivot bushings |
Wheels
| Rims | MDK-HP1 26 TLR, 25mm internal width, tubeless ready, 32 spokes |
|---|---|
| Spokes | CN round stainless steel |
| Front Hub | DA210FS02, 15x100mm, cup & cone ball bearings, IS 6 bolts |
| Rear Hub | Mahle-Ebikemotion X-35, HG freehub |
| Tires | Front: Kenda Regolith 26×2.4 120TPI, Folding TLR, Rear: Kenda Regolith 26×2.4 120TPI, Folding TLR |
Electric Components
| Motor | Mahle-Ebikemotion X-35 |
|---|---|
| Battery | Mahle-Ebikemotion Internal 250Wh |
| Display | Mahle-Ebikemotion |
