Build
| Frame |
Play 20 6061 Alloy Stealth evo, hydroformed tubing, integrated internal non-removable battery, Tapered head tube, HHG internal cable routing, BSA bottom bracket, QR 9mm rear axle, 1x drivetrain compatible BB Standard:Â BSA, 73mm, Threaded |
|---|---|
| Fork |
MDK 20 Kid, Rigid alloy Stealth stanchions, Post Mount disc brake mount |
| Bottom Bracket |
BSA, 73mm |
| Headset |
Onoff Saturn tapered for 1-1/8 to 1-1/2 head tube, ACB sealed bearings, top 41×30.2x7x45x45, bottom 51.9x40x8x45x45 |
| Stem |
Onoff Sulfur FG 30mm 0, 6061 forged alloy, 31.8mm barbore |
| Handlebar |
MDK XC 1.0, 6061 alloy, rise: 25mm, width: 580mm, 9 backsweep, 5 upsweep, 31.8mm barbore |
| Saddle |
SDG Fly Jr |
| Seatpost |
MDK XC 0-R, 6061 T6 Alloy, diameter 31.6mm, length 250mm Type:Â Rigid |
| Grips |
Onoff Twin, 1lock-on |
Groupset
| Rear Derailleur |
Microshift Advent, M6195S super short cage |
|---|---|
| Crank |
Samox DM 28T steel, 127mm, Rings: 28T, steel |
| Shifters |
Microshift Advent SL M6195R, 9s |
| Chain |
SRAM PC951 9s, Powerlock |
| Brakes |
Front: SRAM Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad, Rear: SRAM Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad Type:Â Hydraulic Disc |
| Brake Levers |
SRAM Level, tooled reach adjust, lever pivot bushings |
Wheels
| Rims |
MDK-HP1 20 TLR, 25mm internal width, tubeless ready, 32 spokes |
|---|---|
| Spokes |
CN round stainless steel |
| Front Hub |
K8QF, 9x100mm, cup & cone ball bearings, IS 6 bolts |
| Rear Hub |
Mahle-Ebikemotion X-35, HG freehub |
| Tires |
Front: Kenda Booster 20×2.4 single compound 30TPI, wire bead, Rear: Kenda Booster 20×2.4 single compound 30TPI, wire bead |
Electric Components
| Motor |
Mahle-Ebikemotion X-35 |
|---|---|
| Battery |
Mahle-Ebikemotion Internal 250Wh |
| Display |
Mahle-Ebikemotion |
