2023 Scott Spark 700 A 27.5″ aluminum frame full suspension trail bike with upper mid-range components.
Build
Frame |
Spark 27.5″ Alloy SL 6011 Custom butted hydroformed tubes Tapered headtube / BB92 / Boost 12x148mm BB Standard:Â BB86/BB92, Press Fit |
---|---|
Fork |
X-Fusion RC32 RC 27.5 / 120mm Tapered / 15x110mm / Kids’ Bike Tune |
Rear Shock |
X-Fusion 02Pro RL Trunnion Lockout / Rebound Adjuster / Kids’ Bike Tune Travel 120mm / 165x45mm |
Bottom Bracket |
SRAM DUB Pressfit / MTB 92 |
Headset |
Syncros Pro Press Fit / Tapered 1.5″-1 1/8″ OD 50/61mm / ID 44/55mm |
Stem |
Syncros 6061 Alloy Oversized 31.8mm / 1 1/8″ / 7° angle |
Handlebar |
Syncros T-Bar / Alloy 6061 T shape Flat / 9° / 680mm Syncros Youth 115 |
Saddle |
Syncros Future Pro |
Seatpost |
Syncros Dropper Ducan Remote 31.6mm / 80mm/ Kid centric custom tune |
Groupset
Rear Derailleur |
SRAM NX Eagle 12 Speed |
---|---|
Crank |
SRAM SX Eagle DUB Boost / 155mm / 30T |
Shifters |
SRAM NX Eagle Trigger / MMX |
Cassette |
SRAM SX Eagle / PG-1210 / 11-50 |
Chain |
SRAM CN SX Eagle |
Chain Guide |
SCOTT custom |
Brakes |
Shimano BR-MT500 |
Brake Levers |
Shimano BL-MT501 |
Wheels
Rims |
Syncros X-25 / 32H / 25mm Tubeless ready |
---|---|
Spokes |
Stainless Black 15G / 1.8mm |
Front Hub |
Shimano HB-MT400-B CL / 15x110mm |
Rear Hub |
Shimano FH-MT400-B CL / Boost 12x148mm |
Tires |
Schwalbe Racing Ray Performance / TLR / ADDIX / 27.5×2.25 / 67EPI / folding |
Disk Rotors |
SM-RT54 / CL / 160mm |
