Build
Frame |
Aluminium E – MTB frame designed to take a 720wh battery and Shimano STEPs EP8, E8000 or E7000 motor. The geometry is designed for an all day easy trail ride or a commute to your preferred destination. This is a Step through frame making it easier to get your leg over the TT. This frame has tyre clearance for 29 x 2,6in tyres. Sizes range from S – XL BB Standard:Â STEPS, Press Fit Tire Clearance:Â 2.6in Color:Â Rainbow Pearl |
---|---|
Fork |
Suntour SF19 Raidon32-DS-Boost-RL-R-15QLC32 29 CTS, 120mm Travel, Tapered Steerer, Matt Black, Boost 110mm Thru Axle Travel:Â 120mm Spring Type:Â Air |
Bottom Bracket |
STEPS, press-fit |
Headset |
Token TK035A-15 Sealed Bearing |
Stem |
SURFACE High-Rise alloy |
Handlebar |
SURFACE Alloy, Dia:31.8mm, Backsweep:9, Rise 5mm |
Saddle |
SURFACE E-BIKE saddle, Cromo Rails |
Seatpost |
SURFACE Suspension Post w/Protective Cover, 30.9mm Type:Â Suspension |
Grips |
SURFACE ERGO |
Groupset
Rear Derailleur |
Shimano RD-M5100 Deore, 11 Speed |
---|---|
Crank |
Shimano FC-EM600 |
Shifters |
R: Shimano SL-M5100-R Deore, 11 Speed Rapidfire Plus |
Cassette |
Shimano CS-M5100 Deore, 11 Speed 11-51T |
Chain |
Shimano CN-HG601-11, 11spd |
Brakes |
F: Shimano MT200, Resin Pads Type:Â Hydraulic Disc |
Wheels
Rims |
F: SUNringl Duroc 35, STR Tubeless, 32mm Internal Width |
---|---|
Front Hub |
F: Shimano HB-MT410-B, 32H, 15mm Thru-Axle, 110mm OLD |
Rear Hub |
F: Shimano HB-MT410-B, 32H, 15mm Thru-Axle, 110mm OLD |
Tires |
F: Maxxis Forekaster 29 x 2,35in, 120 tpi, EXO |
Disc Rotors |
F: Shimano SM-RT10 180mm |
Electric Components
Motor |
Shimano EP8 Drive Unit, Mid-Position, 25km/h, 85N.m Torque |
---|---|
Battery |
Darfon 720Wh, 36V, 20Ah Li-Ion, 3.8Kg Weight |
Display |
Shimano SC-E7000, 31.8mm |
Charger |
Darfon Smart Plus, 100-240V, 4A, EU use |
