Build
| Frame |
Aluminium E – MTB frame designed to take a 720wh battery and Shimano STEPs EP8, E8000 or E7000 motor. Battery integrated inside frame.The geometry is designed for trail riding. This frame has tyre clearance for 29 x 2.6in tyres. BB Standard:Â STEPS, Press Fit Tire Clearance:Â 2.6in Color:Â Military-Green-Black |
|---|---|
| Fork |
RockShox 35 Gold RL Debon Air 29in – 140mm – 44mm Offset Travel:Â 140mm Spring Type:Â Air |
| Bottom Bracket |
STEPS, press-fit |
| Headset |
Token TK035A-15 Sealed Bearing |
| Stem |
SURFACE Trail alloy Stem |
| Handlebar |
SURFACE alloy Trail 35mm Handlebar, Backsweep 6, Rise 12mm |
| Saddle |
SURFACE E-bike Ergo |
| Seatpost |
SURFACE Dropper, 30.9mm Type:Â Dropper |
| Grips |
SBC Lockon Grip |
Groupset
| Rear Derailleur |
Shimano RD-M5100 Deore, 11 Speed |
|---|---|
| Crank |
Shimano FC-EM600 |
| Shifters |
R: Shimano SL-M5100-R Deore, 11 Speed Rapidfire Plus |
| Cassette |
Shimano CS-M5100 Deore, 11 Speed 11-51T |
| Chain |
KMC X11-1 11 Speed |
| Brakes |
F: Shimano MT410, Resin Pads Type:Â Hydraulic Disc |
Wheels
| Rims |
F: SUNringl Duroc 35, STR Tubeless ready, 32mm Internal Width |
|---|---|
| Front Hub |
F: Shimano 15x110mm, 6 Bolt |
| Rear Hub |
F: Shimano 15x110mm, 6 Bolt |
| Tires |
F: Maxxis Assegai, 29×2.50WT, EXO+ TR, 3C MaxxTerra |
| Disc Rotors |
F: Shimano SM-RT10 180mm, 6-Bolt |
Electric Components
| Motor |
Shimano EP8 Drive Unit, Mid-Position, 25km/h, 85N.m Torque |
|---|---|
| Battery |
Darfon 720Wh, 36V, 20Ah Li-Ion Battery, 3.8Kg Weight |
| Display |
Shimano SW-E7000, Left |
| Charger |
Darfon Smart Plus Battery Charger, 100-240V, 4A, EU use |
