Build
| Frame | Carbon Fiber Dual Suspension E-bike. Adjustable Chainstay Length for 29in & 27.5in Mullet wheel setup. Rear Travel is 145mm. Garmin 1030 top tube integration or smartphone integration (Garmin device is not included). Fully Integrated cable routing. 720Wh battery with Shimano EP801. Lightweight frame made possible by removing the battery cutout. BB Standard: BSA, 73mm, Threaded Tire Clearance: 2.6in Color: Glacier Shade |
|---|---|
| Fork | Fox Racing Shox 36 Float 29in GRIP Performance Boost E-Optimized fork, 150 mm Travel: 150mm Spring Type: Air |
| Shock | Fox Performance Float DPS, EVOL, 3 Position, Trunnion Travel: 145mm |
| Bottom Bracket | BSA, 73mm, threaded |
| Headset | Token E-Box Headset (ZS56/28.6 l ZS66/40), E-bike Integrated Cable Routing Headset |
| Stem | Surface Trail, Alloy |
| Handlebar | Surface Trail, 35mm Alloy, Backsweep: 6, Rise: 12mm |
| Saddle | Surface Race, Ti Rails |
| Seatpost | Surface Dropper Post with Lever, Dia: 30.9mm Type: Dropper |
| Pedals | Not included |
| Grips | SBC Lockon |
Groupset
| Rear Derailleur | SRAM GX EAGLE LUNAR, 12spd |
|---|---|
| Crank | Shimano XT M8150 |
| Shifters | SRAM GX EAGLE TRIGGER LUNAR, 12spd |
| Cassette | SRAM GX EAGLE LUNAR SRAM XG-1275, 10-52 Eagle |
| Chain | SRAM GX chain, 12spd |
| Brakes | Shimano BL-MT501(L),BR-MT500(F) Type: Hydraulic Disc |
Wheels
| Rims | SUNringle |
|---|---|
| Front Hub | Sunringle |
| Rear Hub | Sunringle |
| Tires | F: Maxxis Assegai 29×2.5in, 120TPI, 3C Maxxgrip |
| Disc Rotors | F: Shimano SM-RT64, 203mm |
Electric Components
| Motor | Shimano EP801, Torque: 85Nm |
|---|---|
| Battery | Li-Ion, 720Wh 36V, 20Ah, 3.8kg |
| Display | Shimano SC-EM800 |
| Charger | Darfon Smart Plus, 4A, 100-240V |
