Build
Frame |
Aluminium 6061, O.L.D.: 135 mm, Brake: postmount disc 7in, BB: Bosch, Cable routing: internal, Fender + rack mounts, Adjustable dropouts, Carrying handle, PowerTube box (lockable) BB Standard:Â Bosch, Press Fit Color:Â Stealth Black |
---|---|
Fork |
SR Suntour Mobie25-Air LOR, Travel: 63 mm, Air suspension, Lockout, Tapered Steerer 1 1/8in – 1 1/2in, O.L.D.: 100 mm, Brake: postmount disc 6in, Fender mounts Travel:Â 63mm Spring Type:Â Air |
Bottom Bracket |
Bosch, press-fit |
Headset |
STEVENS AH Taper 1 1/8in-1 1/2in, Upper bearing cup: ZS44/28.6, Lower bearing cup: ZS55/40 |
Stem |
Oxygen Versa II, adjustable, Handlebar clamp: 31.8 mm, Angle: adjustable (0 – 90) |
Handlebar |
Oxygen E-Scorpo, Width: 680 mm, Backsweep: 5, Rise: 25 mm, Clamp: 31.8 mm |
Saddle |
Selle Royal ON Female |
Seatpost |
Oxygen E-Scorpo DPR-S-E, Travel: 75 mm | 100 mm, Suspension Seatpost, Remote Lockout, Length: 360 mm | 410 mm, Diameter: 30.9 mm, Insertion depth: 100 mm Type:Â Suspension |
Pedals |
ATB Alu Pro Reflex |
Groupset
Crank |
Oxygen E-Scorpo, BB type: Bosch / ISIS, Chainguard |
---|---|
Cassette |
Gates CDX Center Track sprocket, 19 T, Rohloff mount |
Brakes |
Tektro HD-T737, Hydraulic disc brake, 4 pistons Type:Â Tektro Dorado Hydraulic Disc |
Brake Levers |
Tektro HD-T737, 3 finger |
Wheels
Rims |
Oxygen RM-26 Disc SL, ETRTO: 26 x 622 |
---|---|
Front Hub |
Shimano Deore XT, HB-M8010, Axle: QR15x100 mm |
Tires |
Schwalbe Marathon E-Plus Performance, Tire size: 50-622, ADDIX E compound, SmartGuard, Reflective stripes |
Electric Components
Motor |
Bosch G4 Performance Line CX, Continuous rated power: 250 W, Max. torque: 85 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 4 drive modes with support levels 60-340 % plus walk assistance, Mileage: See BOSCH Range Assistant |
---|---|
Battery |
Bosch PowerTube 625, Capacity: 625 Wh/16.7 Ah, Voltage: 36 V, Technology: Li-Ion |
Display |
Bosch Kiox |
Charger |
Bosch 4A charger |
Accessories
Lights |
Front: B+M IQ-XM, Illuminance: 120 lux, 170 lux high beam, Close range light, Rear: Supernova M99 TL 2 Pure, Stationary taillight |
---|---|
Fenders |
SKS mudguards |
Racks |
Racktime Supernova RTA rear rack, Rear rack mount: RTA, System: SNAP IT |
Bell |
STEVENS D85 bell |
