Build
| Frame | Aluminium 6061 DB, O.L.D.: 135 mm, Brake: IS disc, BB: Bosch, Cable routing: internal BB Standard: Bosch, Press Fit Color: Arctic Grey |
|---|---|
| Fork | Rock Shox 35 Silver TK, Travel: 120 mm, Coil spring, Tapered Steerer 1 1/8in – 1.8”, O.L.D.: 110 mm, Brake: postmount disc 7in Travel: 120mm Spring Type: Coil |
| Bottom Bracket | Bosch, press-fit |
| Headset | STEVENS MTB Taper 1 1/8in-1 1/2in, Upper bearing cup: ZS44/28.6, Lower bearing cup: ZS55/40 |
| Stem | Oxygen E-Scorpo, Handlebar clamp: 35 mm, Angle: 5 |
| Handlebar | Oxygen Scorpo, Width: 740 mm, Backsweep: 9, Rise: 25 mm, Clamp: 31.8 mm |
| Saddle | Oxygen Havoc |
| Seatpost | Oxygen E-Scorpo Type: Rigid |
| Pedals | MTB Alu Flatpedal Reflex |
Groupset
| Rear Derailleur | Shimano Deore Shadow+, RD-M5100-SGS, 11-speed, Total capacity: 40 T |
|---|---|
| Crank | Oxygen E-Scorpo, BB type: Bosch / ISIS, Chainguard |
| Shifters | Shimano Deore, SL-M5100-R, 11-speed |
| Cassette | SunRace CSMS8, 11-speed, Combination: 11-13-15-18-21-24-28-33-39-45-51 T |
| Chain | Shimano CN-HG601 |
| Brakes | Tektro HD-M535, Hydraulic disc brake, 4 pistons Type: Tektro Gemini Hydraulic Disc |
| Brake Levers | Tektro HD-M535, 2 finger |
Wheels
| Rims | Oxygen RM-26 Disc, ETRTO: 26 x 622 |
|---|---|
| Front Hub | Strummer CLTP, Axle: QR15x110 mm |
| Rear Hub | Strummer CLTP-1, Axle: QR12x148 mm |
| Tires | Continental eRuban Plus, Tire size: 58-622, Pure-Grip Compound, Reflective stripes |
Electric Components
| Motor | Bosch G4 Performance Line CX, The smart system, Continuous rated power: 250 W, Max. torque: 85 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 4 drive modes with support levels 60-340 % plus walk assistance, Mileage: See BOSCH Range Assistant |
|---|---|
| Battery | Bosch PowerTube 625, The smart system, Capacity: 625 Wh/16.7 Ah, Voltage: 36 V, Technology: Li-Ion |
| Display | Bosch Kiox 300, The smart system |
| Charger | Bosch 4A charger |
Accessories
| Lights | Front: B+M IQ-XS, Illuminance: 100 lux, 7 watt, High beam: 150 lux, 11 watt, Close range light, Rear: Litemove K-Tail |
|---|---|
| Fenders | Curana Apollo mudguards |
| Racks | Racktime Boost rear rack, System: SNAP IT |
| Bell | STEVENS D85 bell |
