Build
| Frame | Aluminium 6061, O.L.D.: 135 mm, Brake: postmount disc 6in, BB: Shimano Steps, Cable routing: internal, Fender + rack mounts BB Standard: STEPS, Press Fit Color: Metallic Green |
|---|---|
| Fork | SR Suntour NX1-Coil LO, Travel: 63 mm, Coil spring, Lockout, Steerer 1 1/8in, O.L.D.: 100 mm, Brake: postmount disc 6in, Fender mounts Travel: 63mm Spring Type: Coil |
| Bottom Bracket | STEPS, press-fit |
| Headset | STEVENS AH 1 1/8in, Upper bearing cup: ZS44/28.6, Lower bearing cup: ZS44/30 |
| Stem | Oxygen Versa II, adjustable, Handlebar clamp: 31.8 mm, Angle: adjustable (0 – 90) |
| Handlebar | Oxygen E-Scorpo, Width: 680 mm, Backsweep: 5, Rise: 25 mm, Clamp: 31.8 mm |
| Saddle | Selle Royal Nuvola Gent |
| Seatpost | Oxygen E-Scorpo, Length: 320 mm, Diameter: 30,9 mm, Insertion depth: min. 100 mm Type: Rigid |
| Pedals | ATB Alu Pro Reflex |
Groupset
| Rear Derailleur | Shimano Deore Shadow+, RD-M5130-GS, 10-speed, Total capacity: 32 T |
|---|---|
| Crank | Shimano FC-E5010, BB type: Shimano Steps |
| Shifters | Shimano Deore, SL-M5130, 10-speed, Linkglide |
| Cassette | Shimano CS-LG400-10, 10-speed, Combination: 11-13-15-17-20-23-26-30-36-43 T, LINKGLIDE |
| Chain | Shimano CN-LG500, LINKGLIDE |
| Brakes | Shimano BR-MT200, Hydraulic disc brake Type: Shimano Hydraulic Disc |
| Brake Levers | Shimano BL-MT200, 3 finger |
Wheels
| Rims | Oxygen RM-26 Disc, ETRTO: 26 x 622 |
|---|---|
| Front Hub | Formula CL-51, Axle: QR5x100 mm |
| Rear Hub | Formula CL-52, Axle: QR5x135 mm |
| Tires | Schwalbe Marathon, Tire size: 47-622, Endurance compound, GreenGuard, Reflective stripes |
Electric Components
| Motor | Shimano Steps E5000, Continuous rated power: 250 W, Max. torque: 40 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 3 drive modes with support levels 70-230 % plus walk assistance, Mileage shimano-steps.com |
|---|---|
| Battery | Shimano Steps BT-E8010, Capacity: 504 Wh/14.0 Ah, Voltage: 36 V, Technology: Li-Ion |
| Display | Shimano SC-E5000 |
| Charger | Shimano 2A charger |
Accessories
| Lights | Front: Trelock I Veo, Illuminance: 50 lux, Rear: Trelock Duo Flat, Stationary taillight |
|---|---|
| Fenders | SKS mudguards |
| Racks | Racktime Eco IMM rear rack, System: SNAP IT |
| Bell | STEVENS D85 bell |
