Build
| Frame | Aluminium 6061 DB, O.L.D.: 148 mm, Brake: postmount disc 7in, BB: Bosch, Cable routing: internal BB Standard: Bosch, Press Fit Color: Sandstone Black |
|---|---|
| Fork | SR Suntour XCR34 Air LOR, Travel: 120 mm, Air suspension, Lockout, Tapered Steerer 1 1/8in – 1 1/2in, O.L.D.: 110 mm, Brake: postmount disc 7in Travel: 120mm Spring Type: Air |
| Bottom Bracket | Bosch, press-fit |
| Headset | STEVENS MTB Taper 1 1/8in-1 1/2in, Upper bearing cup: ZS44/28.6, Lower bearing cup: ZS55/40 |
| Stem | Oxygen E-Scorpo, Handlebar clamp: 31.8 mm, Angle: 5 |
| Handlebar | Oxygen Scorpo, Width: 740 mm, Backsweep: 9, Rise: 25 mm, Clamp: 31.8 mm |
| Saddle | Oxygen Havoc |
| Seatpost | Oxygen E-Scorpo DPR-E, Travel: 100 mm | 125 mm | 150 mm, Remote Lockout, Length: 340 mm | 390 mm | 440 mm, Diameter: 30.9 mm, Insertion depth: 100 mm Type: Dropper |
| Pedals | MTB Flatpedal Reflex |
Groupset
| Rear Derailleur | Shimano CUES U6000 Shadow+, RD-U6000-GS, 10/11-speed, Total capacity: 39 T |
|---|---|
| Crank | e*thirteen e*spec Plus, BB type: Bosch / ISIS, Boost chain line |
| Shifters | Shimano CUES U6000, SL-U6000-11R, 11-speed |
| Cassette | Shimano CS-LG400-11, 11-speed, Combination: 11-13-15-17-20-23-26-30-36-43-50 T |
| Chain | Shimano CN-LG500, LINKGLIDE |
| Brakes | Tektro HD-M535, Hydraulic disc brake, 4 pistons Type: Tektro Gemini Hydraulic Disc |
| Brake Levers | Tektro HD-M530 | 29in: Tektro HD-M535, 2 finger |
Wheels
| Rims | Sun Ringl Droc TR35, ETRTO: 27.5in: 31 x 584 | 29in: 31 x 622 |
|---|---|
| Front Hub | Strummer CLTP, Axle: QR15x110 mm |
| Rear Hub | Strummer CLTP-1, Axle: QR12x148 mm |
| Tires | Schwalbe Nobby Nic Performance, Tire size: 27.5in: 65-584 | 29in: 65-622, Foldable, ADDIX compound, LiteSkin |
Electric Components
| Motor | Bosch G4 Performance Line CX, The smart system, Continuous rated power: 250 W, Max. torque: 85 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 4 drive modes with support levels 60-340 % plus walk assistance, Mileage: See BOSCH Range Assistant |
|---|---|
| Battery | Bosch PowerTube 625, The smart system, Capacity: 625 Wh/16.7 Ah, Voltage: 36 V, Technology: Li-Ion |
| Display | Bosch Purion 200, The smart system |
| Charger | Bosch 4A charger |
