Build
| Frame | Aluminium 6061, O.L.D.: 135 mm, Brake: postmount disc 7in, BB: Bosch, Cable routing: internal, Fender + rack mounts, Adjustable dropouts BB Standard: Bosch, Press Fit Color: Polar Petrol |
|---|---|
| Fork | SR Suntour NX1-Coil LO, Travel: 63 mm, Coil spring, Lockout, Steerer 1 1/8in, O.L.D.: 100 mm, Brake: postmount disc 6in, Fender mounts Travel: 63mm Spring Type: Coil |
| Bottom Bracket | Bosch, press-fit |
| Headset | STEVENS AH 1 1/8in, Upper bearing cup: ZS44/28.6, Lower bearing cup: ZS44/30 |
| Stem | Oxygen Versa II, adjustable, Handlebar clamp: 31.8 mm, Angle: adjustable (0 – 90) |
| Handlebar | Oxygen E-Scorpo, Width: 680 mm, Backsweep: 5, Rise: 25 mm, Clamp: 31.8 mm |
| Saddle | Selle Royal Nuvola Lady |
| Seatpost | Oxygen E-Scorpo, Length: 320 mm, Diameter: 30,9 mm, Insertion depth: min. 100 mm Type: Rigid |
| Pedals | City Reflex |
Groupset
| Crank | Oxygen E-Scorpo, BB type: Bosch / ISIS, Chainguard |
|---|---|
| Shifters | Sunrace S5, Twist shifter for Nexus, 5-speed |
| Cassette | Shimano, 27 T |
| Chain | KMC Z8.1 |
| Brakes | Tektro HD-T280, Hydraulic disc brake, 2 pistons Type: Tektro Hydraulic Disc |
| Brake Levers | Tektro HD-T280, 3 finger |
Wheels
| Rims | Oxygen RM-26 Disc, ETRTO: 26 x 622 |
|---|---|
| Front Hub | Formula DC-20, Axle: QR9x100 mm |
| Tires | Schwalbe Marathon, Tire size: 47-622, Endurance compound, GreenGuard, Reflective stripes |
Electric Components
| Motor | Bosch G3 Active Line Plus, Continuous rated power: 250 W, Max. torque: 50 Nm, Breakaway at 25 km/h (15.5 mph), Mileage: See BOSCH Range Assistant, No of notches: 4 drive modes with support levels 40-270 % plus walk assistance |
|---|---|
| Battery | Bosch PowerPack 400, Capacity: 400 Wh/11.0 Ah, Voltage: 36 V, Technology: Li-Ion |
| Display | Bosch Purion |
| Charger | Bosch 2A charger |
Accessories
| Lights | Front: Trelock I Veo, Illuminance: 50 lux, Rear: Trelock Duo Flat, Stationary taillight |
|---|---|
| Fenders | SKS mudguards |
| Racks | Racktime E-14 RTA rear rack, System: SNAP IT |
| Bell | STEVENS D85 bell |
