Build
Frame |
Aluminium 6061, O.L.D.: 135 mm, Brake: postmount disc 7in, BB: Bosch, Cable routing: internal, Fender + rack mounts, Adjustable dropouts BB Standard:Â Bosch, Press Fit Color:Â Polar Petrol |
---|---|
Fork |
SR Suntour NX1-Coil LO, Travel: 63 mm, Coil spring, Lockout, Steerer 1 1/8in, O.L.D.: 100 mm, Brake: postmount disc 6in, Fender mounts Travel:Â 63mm Spring Type:Â Coil |
Bottom Bracket |
Bosch, press-fit |
Headset |
STEVENS AH 1 1/8in, Upper bearing cup: ZS44/28.6, Lower bearing cup: ZS44/30 |
Stem |
Oxygen Versa II, adjustable, Handlebar clamp: 31.8 mm, Angle: adjustable (0 – 90) |
Handlebar |
Oxygen E-Scorpo, Width: 680 mm, Backsweep: 5, Rise: 25 mm, Clamp: 31.8 mm |
Saddle |
Selle Royal Nuvola Lady |
Seatpost |
Oxygen E-Scorpo, Length: 320 mm, Diameter: 30,9 mm, Insertion depth: min. 100 mm Type:Â Rigid |
Pedals |
City Reflex |
Groupset
Crank |
Oxygen E-Scorpo, BB type: Bosch / ISIS, Chainguard |
---|---|
Shifters |
Sunrace S5, Twist shifter for Nexus, 5-speed |
Cassette |
Shimano, 27 T |
Chain |
KMC Z8.1 |
Brakes |
Tektro HD-T280, Hydraulic disc brake, 2 pistons Type:Â Tektro Hydraulic Disc |
Brake Levers |
Tektro HD-T280, 3 finger |
Wheels
Rims |
Oxygen RM-26 Disc, ETRTO: 26 x 622 |
---|---|
Front Hub |
Formula DC-20, Axle: QR9x100 mm |
Tires |
Schwalbe Marathon, Tire size: 47-622, Endurance compound, GreenGuard, Reflective stripes |
Electric Components
Motor |
Bosch G3 Active Line Plus, Continuous rated power: 250 W, Max. torque: 50 Nm, Breakaway at 25 km/h (15.5 mph), Mileage: See BOSCH Range Assistant, No of notches: 4 drive modes with support levels 40-270 % plus walk assistance |
---|---|
Battery |
Bosch PowerPack 400, Capacity: 400 Wh/11.0 Ah, Voltage: 36 V, Technology: Li-Ion |
Display |
Bosch Purion |
Charger |
Bosch 2A charger |
Accessories
Lights |
Front: Trelock I Veo, Illuminance: 50 lux, Rear: Trelock Duo Flat, Stationary taillight |
---|---|
Fenders |
SKS mudguards |
Racks |
Racktime E-14 RTA rear rack, System: SNAP IT |
Bell |
STEVENS D85 bell |
